82
HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSFORMER >
T801 1-443-172-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
1-861-265-11 POWER SW BOARD
****************
< CAPACITOR >
C805 1-126-795-11 ELECT 10uF 20% 50V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN805 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< DIODE >
D802 6-500-809-01 DIODE SELU5223C-STP15 (STAND BY)
< IC >
IC800 8-759-826-34 IC NJL74H400A ( )
< RESISTOR >
R804 1-216-805-11 METAL CHIP 47 5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R814 1-216-805-11 METAL CHIP 47 5% 1/10W
< SWITCH >
S800 1-762-875-21 SWITCH, KEYBOARD (?/1)
************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C050 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C051 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-922-01 IC SP3723CAF0PM
IC003 6-703-921-01 IC TL343IDBVR
< COIL >
L001 1-412-031-11 INDUCTOR 47uH
L002 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-P
Q002 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 SHORT CHIP 0
R012 1-216-864-11 SHORT CHIP 0
R013 1-216-864-11 SHORT CHIP 0
PANEL POWER SW RF
