HCD-BC150/BC250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R014 1-216-864-11 SHORT CHIP 0
R015 1-216-864-11 SHORT CHIP 0
R016 1-216-864-11 SHORT CHIP 0
R017 1-216-864-11 SHORT CHIP 0
R018 1-216-864-11 SHORT CHIP 0
R019 1-216-864-11 SHORT CHIP 0
R020 1-216-864-11 SHORT CHIP 0
R021 1-216-864-11 SHORT CHIP 0
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 SHORT CHIP 0
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 SHORT CHIP 0
R028 1-216-864-11 SHORT CHIP 0
R029 1-216-864-11 SHORT CHIP 0
R031 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-845-11 METAL CHIP 100K 5% 1/10W
R034 1-216-817-11 METAL CHIP 470 5% 1/10W
R035 1-216-864-11 SHORT CHIP 0
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
R046 1-216-833-11 METAL CHIP 10K 5% 1/10W
R047 1-216-839-11 METAL CHIP 33K 5% 1/10W
R091 1-218-913-91 METAL CHIP 560K 0.5% 1/10W
************************************************************
SENSOR BOARD
*************
< IC >
IC751 8-759-989-76 IC RPR-359F
************************************************************
SPK BOARD
**********
< CAPACITOR >
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C341 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-162-294-31 CERAMIC 0.001uF 10% 50V
C343 1-162-294-31 CERAMIC 0.001uF 10% 50V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C482 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C483 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C484 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C485 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C486 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C487 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C488 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C489 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C490 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C492 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN309 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN311 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN312 1-691-766-21 PLUG (MICRO CONNECTOR) 4P
< TERMINAL >
GP306 1-537-770-21 TERMINAL BOARD, GROUND
GP307 1-537-770-21 TERMINAL BOARD, GROUND
TB301 1-694-998-21 TERMINAL BOARD (SPEAKER)
************************************************************
SW (1) BOARD
************
< SWITCH >
S721 1-786-084-11 SWITCH, DETECTION
************************************************************
SW (2) BOARD
************
< SWITCH >
S731 1-786-382-11 SWITCH, PUSH (1 KEY)
************************************************************
A-4750-232-A TRANSLATION BOARD, COMPLETE
****************************
< CAPACITOR >
C701 1-126-786-11 ELECT 47uF 20% 16V
C702 1-126-791-11 ELECT 10uF 20% 35V
C761 1-162-306-11 CERAMIC 0.01uF 20% 16V
C762 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN701 1-779-558-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
D711 8-719-982-10 DIODE MTZJ-4.3A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q751 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-806-11 CARBON 91 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-430-11 CARBON 12K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
RF SENSOR SW (1) SW (2) TRANSLATIONSPK
