8
HCD-CP333
3-2. Front Panel Section
3-1. Cover (Upper)
1 s
ix screws (+BTP 3
×
8)
4 cover (upper)
2 two case
screw
3 two case
screws
qa s
crew (+KTP 3
×
6)
qs s
crew (+KTP 3
×
6)
qd
front panel section
q; t
wo screws (+BTP 3
×
8)
2 c
onnector 2p (CN810)
3 w
ire (flat type) 11p (CN303)
5 w
ire (flat type) 21p (CN803)
6 w
ire (flat type) 17p (CN801)
8 w
ire (flat type) 17p (CN806)
7 w
ire (flat type) 15p (CN805)
4 w
ire (flat type) 11p (CN302)
1 c
onnector 2p (CN809)
9 c
onnector 4p (CN307)
Note : Follow the disassembly procedure in the numerical order given.
To Next Page
