Sony HCD-CP333 - Tape Mechanism Deck-1; Tape Mechanism Deck-2

9
HCD-CP333
3-3. Tape Mechanism Deck-1
3-4. Tape Mechanism Deck-2
1 two screws (+BVTP 3 × 8)
3
4
5
2 t
hree screws (+BVTP 3 × 8
)
6 t ape machanism deck
1 c assette holder (B) sub assy
3 c assette holder (A)
sub assy
2 s pring (casstte B)
7 w ire (flat type) 11p
(CN401)
qs b racket (MD)
q; TC board
qd w ire (flat type) 11p
4 s pring (cassette A)
5 s crew (+BTP 3 × 8)
8 t wo screws (+BVTP tapping)
qa t hree screws (+BVTP tapping)
qf t wo screws (+BVTTWH tapping)
qg t wo dampers
qh t ape machanism dec
k
6 s hield case (TC)
9 Remove solderings.
