– 2 –
TABLE OF CONTENTS
1. SERVICE NOTES
....................................................... 4
2. GENERAL
Index to Parts and Controls ............................................... 5
3. DISASSEMBLY............................................................ 7
4. ELECTRICAL ADJUSTMENTS
Tuner Section..................................................................... 11
CD Section......................................................................... 12
5. DIAGRAMS
5-1. Block Diagram................................................................... 14
5-2. Printed Wiring Board – BD Section – ............................... 18
5-3. Schematic Diagram – BD Section – .................................. 19
5-4. Schematic Diagram – Main Section – ............................... 22
5-5. Printed Wiring Boards – Main Section –
(US, Canadian model) ....................................................... 27
5-6. Printed Wiring Boards – Main Section –
(Except US, Canadian model) ........................................... 32
5-7. IC Pin Function Description .............................................. 38
6. EXPLODED VIEWS ................................................... 40
7. ELECTRICAL PARTS LIST .................................... 44
Dimensions Approx. 142 × 125 × 252 mm
(w/h/d) (5
5
/
8
× 5 × 10 inches)
incl. projecting parts and controls
Mass Approx. 3 kg (6 lb 10 oz)
Design and specifications are subject to change without notice.
1. Insert the tweezers to a hole on bottom of the
chassis as shown a figure, then tern fully it
toward direction 2.
2. Open the door, pull out the disc table.
1
tweezers
2
4
disc table
cam
3
door
DISC TABLE GETTING OUT PROCEDURE ON THE POWER SUPPLY IS OFF
