– 7 –
Note: Follow the disassembly procedure in the numerical order given.
CASE
SECTION 3
DISASSEMBLY
2
two screws (aluminum)
1
two screws
(case)
3
Remove the case in the
direction of the arrow.
1
two screws
(case)
2
ground terminal
3
connector
(CN401)
5
Pull the front panel assy a little.
4
four screws
(BTTM3
×
6)
7
wire (flat type) (7 core)
(CN504)
8
front panel ass’y
6
wire (flat type) (13 core)
(CN501)
1
wire (flat type) (15 core)
(CN505)
FRONT PANEL ASS’Y
