– 8 –
MAIN BOARD
4 two screws (BV3 × 10)
5 connector
(CN502)
3 two connectors
(CN203, 204)
2 screw (BV3 × 10)
1 indication plate
(pin jack 6p)
6 two covers
(pin jack 2P)
2 two screws
(BV3
× 10)
6 MAIN board
2 three connectors
(CN201, 206, 801)
3 screw
(BV3
× 8)
1 wire (flat type) (19 core)
(CN803)
4 POWER board
3 two screws
(BV3
× 8)
POWER BOARD
