– 44 –
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
CND : Canadian
HK : Hong Kong
JE : Tourist
MY : Malaysia
SP : Singapore
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
SECTION 7
ELECTRICAL PARTS LIST
* 1-657-287-11 A.C. BOARD (US, CND)
* 1-659-292-11 A.C. BOARD (EXCEPT US, CND)
**********
1-533-293-11 FUSE HOLDER
* 4-875-455-31 COVER (DIA. 20), CAPACITOR
< CAPACITOR >
! C1 1-113-916-11 CERAMIC 0.01uF 20% 250V
! C1 1-113-925-11 CERAMIC 0.01uF 20% 250V
(US, CND)
C844 1-164-159-11 CERAMIC 0.1uF 50V
C845 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN1 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN2 1-564-321-00 PIN, CONNECTOR 2P
CN3 1-764-344-11 PIN, CONNECTOR (PCB) (L TYPE) 7P
(EXCEPT US, CND)
* CN3 1-564-522-11 PLUG, CONNECTOR 7P (US, CND)
< FUSE >
! F1 1-532-505-51 FUSE (T5.0AL/250V) (EXCEPT US, CND)
< DIODE >
D813 8-719-987-63 DIODE 1N4148M
< RESISTOR >
R899 1-202-725-00 SOLID 3.3M 10% 1/2W
(US, CND)
< RELAY >
! RY1 1-755-018-11 RELAY
< SWITCH >
! S1 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (EXCEPT US, CND)
< TRANSFORMER >
! T1 1-429-096-11 TRANSFORMER, POWER (EXCEPT US, CND)
! T1 1-429-549-11 TRANSFORMER, POWER (US,CND)
************************************************************
* 1-657-288-11 AU BUS BOARD (US, CND)
* 1-659-289-11 AU BUS BOARD (EXCEPT US, CND)
*************
* 1-690-880-31 LEAD (WITH CONNECTOR)
< CAPACITOR >
C201 1-136-165-00 FILM 0.1uF 5% 50V
C202 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
* CN202 1-565-561-11 PIN, CONNECTOR 3P (AU BUS)
* CN205 1-564-508-11 PLUG, CONNECTOR 5P
< FERRITE BEAD >
FB201 1-412-473-21 INDUCTOR 0UH
FB202 1-412-473-21 INDUCTOR 0UH
< IC >
IC201 8-749-921-12 IC GP1F32T (DIGITAL OUT)
< COIL >
L201 1-410-322-11 INDUCTOR 3.3uH
< RESISTOR >
R203 1-249-433-11 CARBON 22K 5% 1/4W
************************************************************
A-4673-402-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-126-607-11 ELECT CHIP 47uF 20% 4V
C102 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C106 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
When indicating parts by reference
number, please include the board.
A.C. AU BUS BD
