Sony HCD-D290 - Page 24

– 24 –
MAIN SECTION
CD MECHANISM DECK SECTION
1 flat wire (CN202)
2 connector
(CN203)
3 two screws
(BVTP 3
× 8)
3 screw
(BVTP 3
× 8)
3 two screws
(BVTP 3
× 8)
4 main section
3 five screws
(BVTP 3
× 8)
4 CD mechanism
deck section
2 flat wire
and lead wire
1 Open the clamp.
