– 120 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VARIABLE RESISTOR >
RV41 1-238-600-11 ADJ, CARBON 10K (EXCEPT AEP, UK, EE)
RV41 1-238-601-11 ADJ, CARBON 22K (AEP, UK, EE)
RV42 1-238-600-11 ADJ, CARBON 10K (AEP, UK, EE)
RV42 1-238-601-11 ADJ, CARBON 22K (EXCEPT AEP, UK, EE)
RV1701 1-238-600-11 ADJ, CARBON 10K (AEP, UK, EE)
RV1702 1-238-599-11 ADJ, CARBON 4.7K (EE)
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (EXCEPT AEP, UK, EE)
TM1 1-537-488-11 TERMINAL BOARD (ANT) (AEP, UK, EE)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-577-075-11 OSCILLATOR, CERAMIC (456kHz)
(EXCEPT AEP, UK, EE)
X41 1-760-220-11 FILTER, CERAMIC (AEP, UK, EE)
X42 1-527-981-00 FILTER, CERAMIC (AEP, UK, EE)
X42 1-760-220-11 FILTER, CERAMIC (EXCEPT AEP, UK, EE)
X43 1-527-981-00 FILTER, CERAMIC (EXCEPT AEP, UK, EE)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456kHz) (AEP, UK, EE)
************************************************************
* 1-664-014-11 TRANS BOARD
***********
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
* CN901 1-564-522-11 PLUG, CONNECTOR 7P
* CN902 1-564-518-11 PLUG, CONNECTOR 3P
CN903 1-774-108-11 PIN, CONNECTOR (PC BOARD)
< CONNECTOR >
! CNP901 1-558-943-41 CORD, POWER (E, MX, PX)
! CNP901 1-575-042-21 CORD, POWER (US, CND)
! CNP901 1-575-651-21 CORD, POWER (AEP, AR, EE)
! CNP901 1-696-845-11 CORD, POWER (AUS)
! CNP901 1-751-529-11 CORD, POWER (UK)
< FUSE >
! F901 1-532-388-31 FUSE, TIME LAG (2A, 250V) (E, AR, AUS, PX)
! F902 1-532-504-31 FUSE, TIME LAG (4A, 250V) (E, AR, MX, PX)
! F902 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A,125V)
(US, CND)
! F903 1-532-505-31 FUSE, TIME LAG (5A, 250V) (AEP, UK, EE)
! F904 1-532-505-31 FUSE, TIME LAG (5A, 250V) (AEP, UK, EE)
R45 1-247-843-11 CARBON (SMALL) 3.3K 5% 1/4W
(AEP, UK, EE)
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, EE)
R46 1-249-442-11 CARBON 510 5% 1/4W
(EXCEPT AEP, UK, EE)
R47 1-216-097-91 CHIP 100K 5% 1/10W
(2012) (AEP, UK, EE)
R47 1-249-399-11 CARBON 33 5% 1/4W
(EXCEPT AEP, UK, EE)
R48 1-247-843-11 CARBON (SMALL) 3.3K 5% 1/4W
(EXCEPT AEP, UK, EE)
R48 1-249-417-11 CARBON 1K 5% 1/4W
(AEP, UK, EE)
R49 1-216-049-91 CHIP 1.0K 5% 1/10W
(2012) (AEP, UK, EE)
R49 1-249-393-11 CARBON 10 5% 1/4W
(EXCEPT AEP, UK, EE)
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(AEP, UK, EE)
R50 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT AEP, UK, EE)
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(AEP, UK, EE)
R51 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT AEP, UK, EE)
R52 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT AEP, UK, EE)
R53 1-249-425-11 CARBON 4.7K 5% 1/4W
(EXCEPT AEP, UK, EE)
R53 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK, EE)
R54 1-249-425-11 CARBON 4.7K 5% 1/4W
(EXCEPT AEP, UK, EE)
R55 1-216-162-00 CHIP 33 5% 1/8W (3216)
(AEP, UK, EE)
R56 1-249-393-11 CARBON 10 5% 1/4W
(AEP, UK, EE)
R91 1-216-295-91 CONDUCTOR, CHIP (2012) (AEP, UK, EE)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, EE)
R99 1-249-399-11 CARBON 33 5% 1/4W
R1702 1-216-085-00 METAL CHIP 33K 5% 1/10W (EE)
R1703 1-216-069-00 METAL CHIP 6.8K 5% 1/10W (EE)
R1704 1-216-075-00 METAL CHIP 12K 5% 1/10W (EE)
R1708 1-216-095-00 METAL CHIP 82K 5% 1/10W (EE)
R1711 1-249-429-11 CARBON 10K 5% 1/4W (EE)
R1714 1-216-067-00 METAL CHIP 5.6K 5% 1/10W (EE)
R1715 1-216-067-00 METAL CHIP 5.6K 5% 1/10W (EE)
R1718 1-249-429-11 CARBON 10K 5% 1/4W (EE)
R1720 1-249-434-11 CARBON 27K 5% 1/4W (EE)
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
