– 121 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
! R901 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R902 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R903 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(US, CND)
! R903 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(EXCEPT US, CND)
! R904 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(US, CND)
! R904 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(EXCEPT US, CND)
R907 1-202-725-00 SOLID 3.3M 10% 1/2W
(US, CND)
< SWITCH >
! S901 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (E, AR, PX)
< TRANSFORMER >
! T901 1-431-045-11 TRANSFORMER, POWER (US, CND)
! T901 1-431-047-11 TRANSFORMER, POWER (AEP, UK, EE)
! T901 1-431-048-11 TRANSFORMER, POWER (E, AR, MX, AUS, PX)
************************************************************
MISCELLANEOUS
**************
6 1-769-974-11 WIRE (FLAT TYPE) (13 CORE)
(EXCEPT: AEP, EE, UK)
6 1-773-006-11 WIRE (FLAT TYPE) (15 CORE) (AEP, EE, UK)
58 1-773-161-11 WIRE (FLAT TYPE) (21 CORE)
59 1-769-949-11 WIRE (FLAT TYPE) (11 CORE)
120 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
156 1-777-868-11 WIRE (FLAT TYPE) (19 CORE)
! 158 1-569-007-11 ADAPTOR, CONVERSION 2P (PX)
! 159 1-569-008-11 ADAPTOR, CONVERSION 2P (AR)
357 1-452-538-11 MAGNET
! 401 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
402 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP901 1-558-943-41 CORD, POWER (E, MX, PX)
! CNP901 1-575-042-21 CORD, POWER (US, CND)
! CNP901 1-575-651-21 CORD, POWER (AEP, EE, AR)
! CNP901 1-696-845-11 CORD, POWER (AUS)
! CNP901 1-751-529-11 CORD, POWER (UK)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
! T901 1-431-045-11 TRANSFORMER, POWER (US, CND)
!T901 1-431-047-11 TRANSFORMER, POWER (AEP, EE, UK)
! T901 1-431-048-11 TRANSFORMER, POWER (E, AR, MX, AUS, PX)
************************************************************
***************
HARDWARE LIST
***************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#6 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#10 7-623-921-01 RING, RETAINING, CAPSTAN
#11 7-621-775-00 SCREW +B 2.6X3
#12 7-621-255-15 SCREW +P 2X3
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-115-11 COMMANDER, REMOTE (US)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM) (EXCEPT AEP, EE, UK)
1-501-804-11 ANTENNA (FM) (AEP, EE, UK)
3-859-536-11 MANUAL, INSTRUCTION (ENGLISH)
(US, CND, E, AR, MX, AUS, PX)
3-859-536-21 MANUAL, INSTRUCTION (FRENCH) (CND)
3-859-536-31 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(E, AR, MX, PX)
3-859-536-41 MANUAL, INSTRUCTION (CHINESE) (PX)
3-859-537-11 MANUAL, INSTRUCTION (ENGLISH)
(AEP, EE, UK)
3-859-537-21 MANUAL, INSTRUCTION
(FRENCH, SPANISH, PORTUGUESE) (AEP)
3-859-537-31 MANUAL, INSTRUCTION (GERMAN) (AEP)
3-859-537-41 MANUAL, INSTRUCTION
(DUTCH, SWEDISH, ITALIAN) (AEP)
3-859-537-51 MANUAL, INSTRUCTION (DANISH, FINNISH)
(AEP)
3-859-537-61 MANUAL, INSTRUCTION (POLISH, RUSSIAN)
(EE)
8-917-581-90 REMOCON, SONY RM-SD70//M SET
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
