Sony HCD-DX2 - Electrical Parts List Updates

11
AC SW AMP
• ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SW BOARD (E2, E3, SP, TW, AR)
************
< SWITCH >
0S001 1-771-991-11 SLIDE SW (VOLTAGE SELECTOR)
**************************************************************
A-4473-607-A AMP BOARD, COMPLETE (US, CND, MX)
A-4475-001-A AMP BOARD, COMPLETE (AEP, UK)
A-4475-328-A AMP BOARD, COMPLETE (SP, TW, KR, AUS)
A-4475-333-A AMP BOARD, COMPLETE (E2, E3, AR)
*********************
* 1-533-213-31 HOLDER, FUSE (BX2/DX2: KR, MX, AUS)
7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
(BX2/DX2: SP, TW, KR, MX, AUS)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
(BX2/DX2: SP, TW, KR, MX, AUS)
7-685-648-79 SCREW +BVTP3X12 TYPE2 N-S
(BX2/DX2: SP, TW, KR, MX, AUS)
< CAPACITOR >
C400 1-161-494-00 CERAMIC 0.022uF 25V
C401 1-109-953-11 ELECT 2.2uF 20% 50V
C402 1-109-953-11 ELECT 2.2uF 20% 50V
C403 1-162-292-31 CERAMIC 680PF 10% 50V
C404 1-162-292-31 CERAMIC 680PF 10% 50V
C405 1-104-664-11 ELECT 47uF 20% 25V
C406 1-104-664-11 ELECT 47uF 20% 25V
C407 1-126-964-11 ELECT 10uF 20% 50V
(BX2/DX2: SP, TW, KR, MX, AUS)
C407 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C408 1-126-964-11 ELECT 10uF 20% 50V
(BX2/DX2: SP, TW, KR, MX, AUS)
C409 1-164-159-11 CERAMIC 0.1uF 50V
C410 1-126-964-11 ELECT 10uF 20% 50V
(BX2/DX2: SP, TW, KR, MX, AUS)
C410 1-164-159-11 CERAMIC 0.1uF 50V
(E2, E3, AR)
C411 1-126-964-11 ELECT 10uF 20% 50V
(BX2/DX2: SP, TW, KR, MX, AUS)
C411 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C412 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C413 1-162-199-31 CERAMIC 10PF 5% 50V
C414 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-130-777-00 MYLAR 0.1uF 5% 100V
(BX2/DX2: SP, TW, KR, MX, AUS)
C415 1-137-399-11 MYLAR 0.1uF 5% 100V
(E2, E3, AR)
C416 1-130-777-00 MYLAR 0.1uF 5% 100V
(BX2/DX2: SP, TW, KR, MX, AUS)
C416 1-137-399-11 MYLAR 0.1uF 5% 100V
(E2, E3, AR)
C417 1-161-494-00 CERAMIC 0.022uF 25V
C418 1-161-494-00 CERAMIC 0.022uF 25V
C419 1-107-714-11 ELECT 10uF 20% 50V
C421 1-126-933-11 ELECT 100uF 20% 16V
C422 1-126-961-11 ELECT 2.2uF 20% 50V
C423 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C424 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C425 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C426 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C427 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C427 1-164-159-11 CERAMIC 0.1uF 50V
(BX2/DX2: SP, TW, KR, MX, AUS)
C428 1-109-953-11 ELECT 2.2uF 20% 50V
C429 1-162-286-31 CERAMIC 220PF 10% 50V
C430 1-162-286-31 CERAMIC 220PF 10% 50V
C431 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C431 1-161-494-00 CERAMIC 0.022uF 25V
(BX2/DX2: MX)
C432 1-128-582-11 ELECT 10uF 20% 63V
(E2, E3, AR)
C432 1-161-494-00 CERAMIC 0.022uF 25V
(BX2/DX2: MX)
C433 1-126-941-11 ELECT 470uF 20% 25V
(BX2/DX2: MX)
C435 1-161-494-00 CERAMIC 0.022uF 25V
(BX2/DX2: MX)
C437 1-126-933-11 ELECT 100uF 20% 16V
(BX2/DX2: MX)
C438 1-126-933-11 ELECT 100uF 20% 16V
(BX2/DX2: MX)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AR : Argentine model
AUS : Australian model
CND : Canadian model
E2 : 120 V AC Area in E model
E3 : 240 V AC Area in E model
KR : Korean model
MX : Mexican model
SP : Singapore model
TW : Taiwan model
