Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D541 8-719-028-23 DIODE D3SBA20-4101
(AED,AEP,CIS,CND,G,UK)
D541 8-719-510-68 DIODE D5SBA204101
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
D542 8-719-024-99 DIODE 11ES2-NTA2B
D543 8-719-024-99 DIODE 11ES2-NTA2B
D551 8-719-911-19 DIODE 1SS133T-72
< EARTH >
* EP501 1-537-738-21 TERMINAL, EARTH (AED,AEP,CIS,G,UK)
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-93 IC STK402-070 (AED,AEP,CIS,CND,G,UK)
IC501 8-749-016-94 IC STK402-090 (US)
IC501 8-749-016-95 IC STK402-100
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(AED,AEP,CIS,CND,G,UK)
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q582 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
Q583 8-729-900-36 TRANSISTOR BA1F4M-TP
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
Q584 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-416-11 CARBON 820 5% 1/4W F
(AED,AEP,CIS,CND,G,UK)
R503 1-249-415-11 CARBON 680 5% 1/4W F
(US)
R503 1-249-414-11 CARBON 560 5% 1/4W F
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-217-156-00 METAL 0.22 20% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-429-11 CARBON 10K 5% 1/4W
R520 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R521 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R522 1-249-441-11 CARBON 100K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R523 1-249-409-11 CARBON 220 5% 1/4W
F(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R524 1-247-897-11 CARBON 560K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R525 1-249-437-11 CARBON 47K 5% 1/4W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R541 1-260-115-11 CARBON 22K 5% 1/2W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-416-11 CARBON 820 5% 1/4W F
(AED,AEP,CIS,CND,G,UK)
R553 1-249-415-11 CARBON 680 5% 1/4W F
(US)
R553 1-249-414-11 CARBON 560 5% 1/4W F
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-217-156-00 METAL 0.22 20% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-217-156-00 METAL 0.22 20% 5W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-260-115-11 CARBON 22K 5% 1/2W
**************************************************************
A-4724-934-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C104 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C110 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C111 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C112 1-107-682-11 CERAMIC CHIP 1uF 10.00% 16V
C114 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C115 1-104-665-11 ELECT 100uF 20.00% 10V
C116 1-104-665-11 ELECT 100uF 20.00% 10V
C117 1-104-665-11 ELECT 100uF 20.00% 10V
C118 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C119 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
