HCD-DX375
•POWER board service position
Connect the flexible cable and
harnesses from the front panel assy.
Front panel assy
Inshuration sheet
POWER board
DMB12 board
Remove the DMB12 board and
POWER board once.
Then create the service position.
DMB12 board
POWER board
