Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES-CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-91 RES-CHIP 15K 5% 1/10W
R181 1-216-078-00 RES-CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-91 RES-CHIP 15K 5% 1/10W
< RESISTOR NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL 16.9344MHz
**************************************************************
A-4428-077-A CD SWITCH BOARD, COMPLETE
(EXCEPT TH,DX7J)
*************************************
A-4428-905-A CD SWITCH BOARD, COMPLETE (TH)
****************************
A-4473-045-A CD SWITCH BOARD, COMPLETE (DX7J)
******************************
< DIODE >
D630 8-719-056-13 DIODE SML79423C-TP15 (DISC 1)
D631 8-719-056-13 DIODE SML79423C-TP15 (DISC 2)
D632 8-719-056-13 DIODE SML79423C-TP15 (DISC 3)
< TRANSISTOR >
Q630 8-729-422-57 TRANSISTOR BN1A4M-TP
Q631 8-729-422-57 TRANSISTOR BN1A4M-TP
Q632 8-729-422-57 TRANSISTOR BN1A4M-TP
Q633 8-729-422-57 TRANSISTOR BN1A4M-TP
Q634 8-729-422-57 TRANSISTOR BN1A4M-TP
Q635 8-729-422-57 TRANSISTOR BN1A4M-TP
< RESISTOR >
R685 1-249-417-11 CARBON 1K 5% 1/4W F
R686 1-249-418-11 CARBON 1.2K 5% 1/4W F
R687 1-249-420-11 CARBON 1.8K 5% 1/4W F
R688 1-249-422-11 CARBON 2.7K 5% 1/4W F
R689 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-249-406-11 CARBON 120 5% 1/4W F
R751 1-249-406-11 CARBON 120 5% 1/4W F
R752 1-249-406-11 CARBON 120 5% 1/4W F
R753 1-249-406-11 CARBON 120 5% 1/4W F
R754 1-249-406-11 CARBON 120 5% 1/4W F
R755 1-249-406-11 CARBON 120 5% 1/4W F
< SWITCH >
S642 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S643 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S644 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S645 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S646 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE)
**************************************************************
1-675-912-11 DRIVER BOARD
***********
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR (LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-109-66 DIODE MTZJ-T-77-3.3B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-676-220-11 HEAD (A) BOARD
************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD (B) BOARD
************
< CONNECTOR >
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
**********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
BD DRIVER HEAD (A) HEAD (B)
CD SWITCH
LEAF SW
