65
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C780 1-162-282-31 CERAMIC 100PF 10% 50V
C781 1-162-282-31 CERAMIC 100PF 10% 50V
C782 1-162-282-31 CERAMIC 100PF 10% 50V
C783 1-162-282-31 CERAMIC 100PF 10% 50V
C784 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN601 1-793-767-11 CONNECTOR, BOARD TO BOARD 30P
< DIODE >
D601 8-719-057-30 DIODE HLMF-K205-2UL (@/1)
D602 8-719-063-93 DIODE SLR325VC-N-T32 (TIMER SELECT)
D603 8-719-109-89 DIODE MTZJ-T-77-5.6C
D611 8-719-071-41 DIODE SELS5923C-TP15 (GROOVE)
D612 8-719-071-41 DIODE SELS5923C-TP15 (CURSOL)
D613 8-719-071-41 DIODE SELS5923C-TP15 (CURSOL)
D614 8-719-071-41 DIODE SELS5923C-TP15 (V-GROOVE)
D615 8-719-072-82 DIODE SELU5E20C-STP15 (FUNCTION)
D617 8-719-063-93 DIODE SLR325VC-N-T32 (REC/PAUSE)
D618 8-719-071-41 DIODE SELS5923C-TP15 (SURROUND)
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
FB602 1-412-473-21 INDUCTOR 0UH
FB603 1-412-473-21 INDUCTOR 0UH (EXCEPT TH)
< FILTER >
FL601 1-517-928-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-652-49 IC TMP88CP77F-1A22
IC602 8-759-570-21 IC BA3830F-E2
IC603 8-759-648-23 IC RPM6940-H4
IC721 8-759-496-40 IC M65850FP (EA,DX7J)
IC722 8-759-634-51 IC M5218AP (DX7,DX7J)
< JACK >
J631 1-785-569-11 JACK (SMALL TYPE) (PHONE)
J721 1-785-569-11 JACK (SMALL TYPE) (MIC1) (DX7,DX7J)
J722 1-785-569-11 JACK (SMALL TYPE) (MIC2) (EA,DX7J)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q604 8-729-900-80 TRANSISTOR BA1A4M-TP
Q605 8-729-900-80 TRANSISTOR BA1A4M-TP
Q606 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q607 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q608 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q609 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q610 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q611 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q612 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q613 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q614 8-729-900-74 TRANSISTOR BA1L3Z-TP
Q615 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q621 8-729-900-80 TRANSISTOR BA1A4M-TP
Q622 8-729-900-80 TRANSISTOR BA1A4M-TP
Q623 8-729-900-80 TRANSISTOR BA1A4M-TP
Q624 8-729-900-80 TRANSISTOR BA1A4M-TP
Q625 8-729-900-80 TRANSISTOR BA1A4M-TP
Q626 8-729-900-80 TRANSISTOR BA1A4M-TP
Q721 8-729-119-79 TRANSISTOR 2SC2785TP-FEK (DX7,DX7J)
< RESISTOR >
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R605 1-247-903-00 CARBON 1M 5% 1/4W
R606 1-247-807-31 CARBON 100 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-247-807-31 CARBON 100 5% 1/4W
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-807-31 CARBON 100 5% 1/4W
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-401-11 CARBON 47 5% 1/4W F
R613 1-247-893-11 CARBON 390K 5% 1/4W
R614 1-247-893-11 CARBON 390K 5% 1/4W
R615 1-249-441-11 CARBON 100K 5% 1/4W
R616 1-249-440-11 CARBON 82K 5% 1/4W
R617 1-249-429-11 CARBON 10K 5% 1/4W
R618 1-249-441-11 CARBON 100K 5% 1/4W
R619 1-249-441-11 CARBON 100K 5% 1/4W
R620 1-249-437-11 CARBON 47K 5% 1/4W
R621 1-249-440-11 CARBON 82K 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
R623 1-249-431-11 CARBON 15K 5% 1/4W
R625 1-249-435-11 CARBON 33K 5% 1/4W
R626 1-247-895-91 CARBON 470K 5% 1/4W
R633 1-249-411-11 CARBON 330 5% 1/4W
R634 1-249-407-11 CARBON 150 5% 1/4W F
R635 1-249-401-11 CARBON 47 5% 1/4W F
R636 1-249-441-11 CARBON 100K 5% 1/4W
R637 1-249-441-11 CARBON 100K 5% 1/4W
R638 1-249-441-11 CARBON 100K 5% 1/4W
R639 1-249-441-11 CARBON 100K 5% 1/4W
R640 1-249-441-11 CARBON 100K 5% 1/4W
R641 1-249-441-11 CARBON 100K 5% 1/4W
R642 1-249-441-11 CARBON 100K 5% 1/4W
R643 1-249-441-11 CARBON 100K 5% 1/4W
R644 1-249-441-11 CARBON 100K 5% 1/4W
R651 1-249-429-11 CARBON 10K 5% 1/4W
R652 1-249-410-11 CARBON 270 5% 1/4W F
R653 1-249-411-11 CARBON 330 5% 1/4W
R654 1-249-413-11 CARBON 470 5% 1/4W F
R655 1-249-415-11 CARBON 680 5% 1/4W F
R656 1-249-417-11 CARBON 1K 5% 1/4W F
R657 1-249-418-11 CARBON 1.2K 5% 1/4W F
R658 1-249-418-11 CARBON 1.2K 5% 1/4W F
R659 1-249-417-11 CARBON 1K 5% 1/4W F
R660 1-249-420-11 CARBON 1.8K 5% 1/4W F
R661 1-247-843-11 CARBON 3.3K 5% 1/4W
R662 1-249-425-11 CARBON 4.7K 5% 1/4W F
R664 1-249-429-11 CARBON 10K 5% 1/4W
R665 1-249-410-11 CARBON 270 5% 1/4W F
R666 1-249-411-11 CARBON 330 5% 1/4W
R667 1-249-413-11 CARBON 470 5% 1/4W F
R668 1-249-414-11 CARBON 560 5% 1/4W F
R669 1-249-414-11 CARBON 560 5% 1/4W F
R670 1-249-415-11 CARBON 680 5% 1/4W F
R671 1-249-422-11 CARBON 2.7K 5% 1/4W F
PANEL
