Sony HCD-DX7 - Page 68

68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R523 1-249-441-11 CARBON 100K 5% 1/4W
(DX7,DX7J)
R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W
(DX7,DX7J)
R541 1-249-441-11 CARBON 100K 5% 1/4W
(DX7,DX7J)
R541 1-249-437-11 CARBON 47K 5% 1/4W
(BX7)
R542 1-249-441-11 CARBON 100K 5% 1/4W
(DX7,DX7J)
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-411-11 CARBON 390 5% 1/4W
(DX7,DX7J)
R553 1-249-414-11 CARBON 560 5% 1/4W F
(BX7)
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
R558 1-220-891-11 METAL 0.1 10% 5W
(DX7,DX7J)
R558 1-217-156-00 METAL 0.22 20% 5W
(BX7)
R559 1-260-076-11 CARBON 10 5% 1/2W
R560 1-220-891-11 METAL 0.1 10% 5W
(DX7,DX7J)
R560 1-217-156-00 METAL 0.22 20% 5W
(BX7)
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
(DX7,DX7J)
R591 1-249-437-11 CARBON 47K 5% 1/4W
(BX7)
R592 1-249-441-11 CARBON 100K 5% 1/4W
(DX7,DX7J)
R941 1-216-478-11 METAL OXIDE 390 5% 3W
(DX7,DX7J)
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W F
R944 1-247-791-91 CARBON 22 5% 1/4W
(DX7,DX7J)
R980 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR (DX7,DX7J)
**************************************************************
1-675-911-11 SENSOR BOARD
************
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-247-815-91 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
**************************************************************
A-4428-301-A SUB-TRANS BOARD, COMPLETE
(AEP,G,UK,CIS)
************************************
A-4428-959-A SUB-TRANS BOARD, COMPLETE (CND)
*****************************
A-4473-194-A SUB-TRANS BOARD, COMPLETE (US)
*****************************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
(US)
C973 1-126-933-11 ELECT 100uF 20.00% 16V
(BX7)
C975 1-126-768-11 ELECT 2200uF 20.00% 16V
(BX7)
C976 1-164-159-21 CERAMIC 0.1uF 50V (BX7)
C977 1-164-159-21 CERAMIC 0.1uF 50V (BX7)
C978 1-164-159-21 CERAMIC 0.1uF 50V (BX7)
< CONNECTOR >
CN974 1-564-321-00 PIN, CONNECTOR 2P (BX7)
CN976 1-506-468-11 PIN, CONNECTOR 3P (BX7)
< DIODE >
0D971 8-719-991-33 DIODE 1SS133T-77 (BX7)
D972 8-719-024-99 DIODE 11ES2-NTA2B (BX7)
D973 8-719-024-99 DIODE 11ES2-NTA2B (BX7)
D974 8-719-024-99 DIODE 11ES2-NTA2B (BX7)
D975 8-719-024-99 DIODE 11ES2-NTA2B (BX7)
< IC >
IC971 8-759-039-69 IC uPC7805AHF (BX7)
< TRANSISTOR >
Q971 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (BX7)
< RESISTOR >
R974 1-249-441-11 CARBON 100K 5% 1/4W (BX7)
R975 1-249-429-11 CARBON 10K 5% 1/4W (BX7)
< RELAY >
0RY971 1-755-276-11 RELAY, POWER (BX7)
< TRANSFORMER >
0T972 1-435-209-21 TRANSFORMER, POWER (US,CND)
0T972 1-435-210-11 TRANSFORMER, POWER (AEP,G,UK,CIS)
**************************************************************
A-4428-089-A TRANS BOARD, COMPLETE (US)
*************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER AMP
SENSOR SUB-TRANS TRANS
