79
HCD-DZ119/DZ410
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3555 1-216-864-11 SHORT CHIP 0
R4002 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1113 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1114 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1115 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X502 1-795-058-21 VIBRATOR, CERAMIC 5MHz
X1102 1-813-539-11 QUARTZ CRYSTAL UNIT 27MHz
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
*************************************************************
MS-203 BOARD
*************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
*************************************************************
A-1144-737-A POWER BOARD, COMPLETE (DZ119)
A-1177-660-A POWER BOARD, COMPLETE (DZ410)
**********************
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-332-11 ELECT (BLOCK) 330uF 20% 400V
0 C905 1-112-335-91 FILM 0.0033uF 5% 400V
0 C906 1-117-815-11 FILM 1000PF 3% 1.5KV
0 C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C908 1-107-909-11 ELECT 47uF 20% 35V
0 C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C910 1-126-965-91 ELECT 22uF 20% 50V
0 C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0C924 1-126-961-11 ELECT 2.2uF 20% 50V
0C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0C928 1-113-900-11 CERAMIC 470PF 10% 250V
0C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0C930 1-117-693-11 CERAMIC 100PF 10% 250V
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
(DZ410)
C934 1-126-953-11 ELECT 2200uF 20% 35V
(DZ119)
C935 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C936 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 50V
0C938 1-117-698-51 CERAMIC 680PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
C945 1-126-935-11 ELECT 470uF 20% 16V
C946 1-128-950-21 ELECT 1000uF 20% 16V
C947 1-104-658-91 ELECT 100uF 20% 10V
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-165-722-11 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C958 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C960 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0C963 1-117-699-11 CERAMIC 0.001uF 99% 250V
0C964 1-117-699-11 CERAMIC 0.001uF 99% 250V
C965 1-117-699-11 CERAMIC 0.001uF 99% 250V
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C969 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C970 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C971 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0D901 8-719-082-57 DIODE D5SBA60F01
0D905 8-719-063-74 DIODE D1NL20U-TR2
0D906 6-501-193-01 DIODE 1SS355WTE-17
0D907 6-501-193-01 DIODE 1SS355WTE-17
0D908 6-501-193-01 DIODE 1SS355WTE-17
0D909 6-501-193-01 DIODE 1SS355WTE-17
0D910 6-501-193-01 DIODE 1SS355WTE-17
0D913 6-500-241-01 DIODE SARS03
0D914 6-501-193-01 DIODE 1SS355WTE-17
0D915 8-719-977-28 DIODE UDZSTE-1710B
0D921 6-501-424-01 DIODE STO2D-140
MAIN MS-203 POWER
