80
HCD-DZ119/DZ410
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
0 D922 8-719-063-74 DIODE D1NL20U-TR2
0 D923 8-719-977-28 DIODE UDZSTE-1710B
0 D924 8-719-083-69 DIODE UDZSTE-1724B
0 D925 8-719-069-54 DIODE UDZSTE-175.1B
0 D926 8-719-977-28 DIODE UDZSTE-1710B
D931 6-501-413-01 DIODE FCU20UC20
D932 8-719-069-54 DIODE UDZSTE-175.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 8-719-083-67 DIODE UDZSTE-1720B
< GROUND TERMINAL BOARD >
EB901 1-537-770-21 TERMINAL BOARD, GROUND (DZ410)
* EB901 1-537-738-21 TERMINAL, EARTH (DZ119)
EB902 1-537-770-21 TERMINAL BOARD, GROUND (DZ410)
* EB902 1-537-738-21 TERMINAL, EARTH (DZ119)
EB903 1-537-770-21 TERMINAL BOARD, GROUND (DZ410)
* EB903 1-537-738-21 TERMINAL, EARTH (DZ119)
EB904 1-537-770-21 TERMINAL BOARD, GROUND (DZ410)
* EB904 1-537-738-21 TERMINAL, EARTH (DZ119)
< FUSE HOLDER >
0 FH901 1-533-217-41 HOLDER, FUSE (DZ119)
0 FH901 1-533-313-11 FUSE HOLDER 0A 0V (DZ410)
0 FH902 1-533-217-41 HOLDER, FUSE (DZ119)
0 FH902 1-533-313-11 FUSE HOLDER 0A 0V (DZ410)
< FUSIBLE >
0 FR901 1-220-886-11 FUSIBLE 0.1 10% 1W
< IC >
0 IC901 6-707-742-01 IC STR-F6168-LF1352
0 IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-707-746-01 IC SI-3120KM-TL
IC942 6-707-745-10 IC SI-3050KM-TL
IC943 6-707-744-01 IC SI-3033KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-226-11 INDUCTOR 10uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-079-11 COIL, LINE FILTER
0 LF902 1-457-079-11 COIL, LINE FILTER
< IC >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
0 Q901 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 8-729-027-59 TRANSISTOR DTC144EKA-T146
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 8-729-027-59 TRANSISTOR DTC144EKA-T146
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W
0 R903 1-215-929-11 METAL OXIDE 100K 5% 3W
0 R904 1-215-929-11 METAL OXIDE 100K 5% 3W
0 R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R908 1-260-105-11 CARBON 3.3K 5% 1/2W
0 R909 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R912 1-216-363-00 METAL OXIDE 0.33 5% 2W
0 R914 1-219-718-11 METAL 0.1 10% 5W
0 R919 1-216-836-11 METAL CHIP 18K 5% 1/10W
0 R922 1-216-793-11 METAL CHIP 4.7 5% 1/10W
0 R923 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R926 1-216-855-11 METAL CHIP 680K 5% 1/10W
0 R927 1-216-349-00 METAL OXIDE 1 5% 1W
0 R929 1-249-478-11 CARBON 2.2 5% 1/2W
R931 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R932 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R941 1-216-864-11 SHORT CHIP 0
R943 1-216-864-11 SHORT CHIP 0
R946 1-216-811-11 METAL CHIP 150 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R952 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R953 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R954 1-216-837-11 METAL CHIP 22K 5% 1/10W
R955 1-216-817-11 METAL CHIP 470 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
R968 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R969 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-864-11 SHORT CHIP 0
