Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC599
40
C414 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C415 1-114-334-11 CERAMIC CHIP 10uF 10% 25V
C416 1-114-334-11 CERAMIC CHIP 10uF 10% 25V
C500 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C501 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C503 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C507 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C509 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C510 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C511 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C512 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C513 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C515 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C516 1-126-176-11 ELECT 220uF 20% 10V
C517 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C520 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-126-157-11 ELECT 10uF 20% 16V
C522 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C524 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C525 1-126-157-11 ELECT 10uF 20% 16V
C526 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C531 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C549 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C551 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C553 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C555 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C557 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C559 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C560 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C561 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C563 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C572 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C574 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C575 1-126-157-11 ELECT 10uF 20% 16V
C576 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN100 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN200 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN300 1-568-838-11 CONNECTOR, FFC 21P
CN400 1-819-866-11 USB CONNECTOR (A) (
)
CN500 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D100 6-503-429-01 DI 1L034XY24H0CA601
D109 6-502-961-01 DI DA2J10100L
D119 6-500-335-01 DIODE MC2838-T112-1
D122 6-500-335-01 DIODE MC2838-T112-1
D302 6-500-334-01 DIODE MC2836-T112-1
D303 6-502-961-01 DI DA2J10100L
D313 6-502-961-01 DI DA2J10100L
D320 6-503-011-01 DI DZ2J039M0L
D321 6-500-522-21 DIODE 10EDB40-TB3
D322 6-500-522-21 DIODE 10EDB40-TB3
D345 6-500-848-01 DIODE MC2840-T112-1
D380 6-500-848-01 DIODE MC2840-T112-1
D401 6-500-848-01 DIODE MC2840-T112-1
D402 6-500-848-01 DIODE MC2840-T112-1
D404 6-502-970-01 DI DZ2J068M0L
D405 6-502-970-01 DI DZ2J068M0L
D407 6-500-522-21 DIODE 10EDB40-TB3
D408 6-500-522-21 DIODE 10EDB40-TB3
D409 6-500-522-21 DIODE 10EDB40-TB3
D549 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB400 1-216-295-91 SHORT CHIP 0
FB401 1-216-295-91 SHORT CHIP 0
< IC >
IC100 A-1863-397-A IC LC87F7DJ2CVU-QIP-H (for SERVICE)
IC129 6-600-768-01 IC PNA4823M03S0
IC300 6-703-639-01 IC TK11140CSCL-G
IC301 6-701-680-01 IC PST3629NR
IC400 6-717-879-01 IC RT8293ALZSP
IC500 6-713-384-01 IC BD3491FS-SE2
< JACK >
J380 1-842-549-11 JACK (PHONES)
J500 1-842-550-11 JACK BLOCK, PIN 2P (DVD/PC IN)
< JUMPER RESISTOR >
JR100 1-216-296-11 SHORT CHIP 0
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-296-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR111 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR501 1-216-295-91 SHORT CHIP 0
< COIL >
L400 1-456-509-21 INDUCTOR 10uH
L502 1-500-445-21 FERRITE, EMI (SMD) (2012)
< LIQUID CRYSTAL DISPLAY >
LCD100 1-811-042-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q131 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q187 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q231 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q300 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q320 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q321 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q400 6-551-696-01 TR ISA1235AC1-T112-1EF
< RESISTOR >
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-864-11 SHORT CHIP 0
PANEL
