Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC599
42
R558 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R560 1-216-864-11 SHORT CHIP 0
R571 1-216-864-11 SHORT CHIP 0
< ROTARY ENCODER >
S350 1-786-417-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
SW350 1-771-410-21 SWITCH, TACT (I/
1
)
SW360 1-771-410-21 SWITCH, TACT (TUNING +
ML
)
SW361 1-771-410-21 SWITCH, TACT (u)
SW362 1-771-410-21 SWITCH, TACT (TUNING -
lm
)
SW363 1-771-410-21 SWITCH, TACT (ENTER)
SW364 1-771-410-21 SWITCH, TACT (DSGX)
SW365 1-771-410-21 SWITCH, TACT (EQ)
SW370 1-771-410-21 SWITCH, TACT (FUNCTION)
SW371 1-771-410-21 SWITCH, TACT (
+
)
SW372 1-771-410-21 SWITCH, TACT (
x
)
SW373 1-771-410-21 SWITCH, TACT (
-
)
SW374 1-771-410-21 SWITCH, TACT (REC TO USB)
SW375 1-771-410-21 SWITCH, TACT (OPTIONS)
< VIBRATOR >
X112 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X115 1-814-474-21 CELAMIC OSCILLATOR (18MHz)
*************************************************************
POWER BOARD
************
< CAPACITOR >
C701 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C702 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C703 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C704 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C705 1-115-870-11 ELECT 0.47uF 20% 50V
C706 1-115-870-11 ELECT 0.47uF 20% 50V
C707 1-119-943-91 ELECT 47uF 20% 50V
C708 1-119-943-91 ELECT 47uF 20% 50V
C709 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C710 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C711 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C712 1-126-382-11 ELECT 100uF 20% 16V
C713 1-128-126-11 ELECT 100uF 20% 25V
C714 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C715 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C717 1-126-514-11 ELECT 22uF 20% 16V
C723 1-126-968-11 ELECT 100uF 20% 50V
C724 1-126-968-11 ELECT 100uF 20% 50V
C725 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C732 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C733 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C734 1-126-974-11 ELECT 3300uF 20% 50V
C735 1-126-974-11 ELECT 3300uF 20% 50V
C736 1-126-943-11 ELECT 2200uF 20% 25V
C739 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C740 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C741 1-126-382-11 ELECT 100uF 20% 16V
C742 1-126-785-11 ELECT 47uF 20% 10V
C751 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C753 1-115-872-11 ELECT 2.2uF 20% 50V
C755 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C756 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C757 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C758 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C759 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C762 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN701 1-564-506-11 PLUG, CONNECTOR 3P
CN704 1-568-838-11 SOCKET, CONNECTOR 21P
* CN722 1-564-511-11 PLUG, CONNECTOR 8P
< DIODE >
D706 6-502-961-01 DI DA2J10100L
D707 6-502-619-01 DI 1N5402-C532-2
D708 6-502-619-01 DI 1N5402-C532-2
D709 6-502-619-01 DI 1N5402-C532-2
D710 6-502-619-01 DI 1N5402-C532-2
D711 6-500-522-21 DIODE 10EDB40-TB3
D712 6-500-522-21 DIODE 10EDB40-TB3
D715 6-502-961-01 DI DA2J10100L
D717 6-500-335-01 DIODE MC2838-T112-1
D718 6-502-961-01 DI DA2J10100L
D721 6-500-335-01 DIODE MC2838-T112-1
D723 6-503-028-01 DI DZ2J130M0L
< IC >
IC701 6-718-464-01 IC STK433-040N-E
IC702 6-713-032-01 IC KIA7809API-U/PF
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR703 1-216-296-11 SHORT CHIP 0
JR704 1-216-864-11 SHORT CHIP 0
JR705 1-216-864-11 SHORT CHIP 0
JR706 1-216-296-11 SHORT CHIP 0
< COIL >
L701 1-456-107-11 COIL, AIR-CORE
L702 1-456-107-11 COIL, AIR-CORE
< TRANSISTOR >
Q704 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q705 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q707 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q708 6-551-696-01 TR ISA1235AC1-T112-1EF
Q709 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q710 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q711 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q712 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q713 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q715 6-551-696-01 TR ISA1235AC1-T112-1EF
Q716 6-551-696-01 TR ISA1235AC1-T112-1EF
Q720 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q721 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q728 8-729-023-22 TRANSISTOR 2SD2114K
< RESISTOR >
R701 1-216-817-11 METAL CHIP 470 5% 1/10W
R702 1-216-817-11 METAL CHIP 470 5% 1/10W
POWERPANEL
