Sony HCD-EC98P - Page 54

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC98P
54
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-845-11 METAL CHIP 100K 5% 1/10W
R120 1-216-864-11 SHORT CHIP 0
R125 1-216-864-11 SHORT CHIP 0
R126 1-216-864-11 SHORT CHIP 0
R127 1-216-864-11 SHORT CHIP 0
R128 1-216-853-11 METAL CHIP 470K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-857-11 METAL CHIP 1M 5% 1/10W
R135 1-216-853-11 METAL CHIP 470K 5% 1/10W
R136 1-216-837-11 METAL CHIP 22K 5% 1/10W
R139 1-216-841-11 METAL CHIP 47K 5% 1/10W
R140 1-216-864-11 SHORT CHIP 0
R142 1-216-837-11 METAL CHIP 22K 5% 1/10W
R143 1-216-841-11 METAL CHIP 47K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R145 1-216-864-11 SHORT CHIP 0
R146 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
R149 1-216-864-11 SHORT CHIP 0
R150 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-857-11 METAL CHIP 1M 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-91 SHORT CHIP 0
R202 1-216-295-91 SHORT CHIP 0
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-809-11 METAL CHIP 100 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R304 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1379-815-A DMP BOARD, COMPLETE
********************
3-276-209-01 BRACKET (DMPORT)
< CONNECTOR >
CN901 1-817-615-21 CONNECTOR, SQUARE TYPE (RECE) (DMPORT)
CN902 1-784-863-51 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< JUMPER RESISTOR >
R904 1-216-864-11 SHORT CHIP 0
R905 1-216-864-11 SHORT CHIP 0
R906 1-216-864-11 SHORT CHIP 0
R907 1-216-864-11 SHORT CHIP 0
R908 1-216-864-11 SHORT CHIP 0
************************************************************
HI AMP BOARD
************
< CAPACITOR >
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-126-960-11 ELECT 1uF 20% 50V
C153 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C154 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C155 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C156 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C157 1-126-960-11 ELECT 1uF 20% 50V
C158 1-126-960-11 ELECT 1uF 20% 50V
C159 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C160 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C166 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C169 1-126-968-11 ELECT 100uF 20% 50V (AUS)
C169 1-128-576-11 ELECT 100uF 20% 63V
(US, CND)
C170 1-126-968-11 ELECT 100uF 20% 50V (AUS)
C170 1-128-576-11 ELECT 100uF 20% 63V
(US, CND)
C173 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C174 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C175 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C176 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C178 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN151 1-819-134-11 PIN, CONNECTOR 6P
CN152 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D151 6-500-335-01 DIODE MC2838-T112-1
D152 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC152 6-600-580-01 IC STK433-090-E
CD DMP HI AMP
