Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC98P
5555
< JUMPER RESISTOR >
JR151 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q151 6-551-270-01 TRANSISTOR 2SA2026
Q152 6-551-270-01 TRANSISTOR 2SA2026
< RESISTOR >
R151 1-216-813-11 METAL CHIP 220 5% 1/10W
R152 1-216-813-11 METAL CHIP 220 5% 1/10W
R153 1-216-837-11 METAL CHIP 22K 5% 1/10W
R154 1-216-837-11 METAL CHIP 22K 5% 1/10W
R155 1-216-841-11 METAL CHIP 47K 5% 1/10W
R156 1-216-841-11 METAL CHIP 47K 5% 1/10W
R159 1-216-821-11 METAL CHIP 1K 5% 1/10W
R160 1-216-821-11 METAL CHIP 1K 5% 1/10W
R161 1-216-817-11 METAL CHIP 470 5% 1/10W
R162 1-216-817-11 METAL CHIP 470 5% 1/10W
R163 1-216-841-11 METAL CHIP 47K 5% 1/10W
R164 1-216-841-11 METAL CHIP 47K 5% 1/10W
R171 1-216-864-11 SHORT CHIP 0
R172 1-216-809-11 METAL CHIP 100 5% 1/10W
R173 1-216-821-11 METAL CHIP 1K 5% 1/10W
R175 1-216-813-11 METAL CHIP 220 5% 1/10W
R176 1-216-813-11 METAL CHIP 220 5% 1/10W
R177 1-216-813-11 METAL CHIP 220 5% 1/10W
R178 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R179 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R180 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R181 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R182 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R183 1-216-837-11 METAL CHIP 22K 5% 1/10W
R184 1-216-837-11 METAL CHIP 22K 5% 1/10W
R185 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R186 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R195 1-216-817-11 METAL CHIP 470 5% 1/10W
R196 1-216-817-11 METAL CHIP 470 5% 1/10W
************************************************************
JACK BOARD
***********
< CAPACITOR >
C491 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C495 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C496 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< JACK >
J491 1-566-822-51 JACK (AUDIO IN)
J492 1-815-629-21 JACK (PHONES)
< RESISTOR >
R491 1-216-837-11 METAL CHIP 22K 5% 1/10W
R492 1-216-837-11 METAL CHIP 22K 5% 1/10W
************************************************************
KEY CD BOARD
*************
< RESISTOR >
R407 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R408 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R409 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R410 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(AUS)
R411 1-216-835-11 METAL CHIP 15K 5% 1/10W
(AUS)
< SWITCH >
SW306 1-771-410-21 SWITCH, TACTILE (CD) (US, CND)
SW306 1-771-410-21 SWITCH, TACTILE (DISC 1) (AUS)
SW307 1-771-410-21 SWITCH, TACTILE (DMPORT) (US, CND)
SW307 1-771-410-21 SWITCH, TACTILE (DISC 2) (AUS)
SW308 1-771-410-21 SWITCH, TACTILE (Z) (US, CND)
SW308 1-771-410-21 SWITCH, TACTILE (DISC 3) (AUS)
SW309 1-771-410-21 SWITCH, TACTILE (Z) (AUS)
SW310 1-771-410-21 SWITCH, TACTILE (DISC SKIP/EX-CHANGE)
(AUS)
************************************************************
KEY POWER BOARD
*****************
< SWITCH >
SW301 1-771-410-21 SWITCH, TACTILE (I/1, STANDBY)
SW302 1-771-410-21 SWITCH, TACTILE (SUBWOOFER ON/OFF)
< CABLE HOLDER >
W401 1-824-027-21 HOLDER, CABLE 3P
************************************************************
LOW AMP BOARD
**************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-126-947-11 ELECT 47uF 20% 35V
C108 1-126-947-11 ELECT 47uF 20% 35V
C109 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C110 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C111 1-126-960-11 ELECT 1uF 20% 50V
C112 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C113 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C114 1-126-947-11 ELECT 47uF 20% 35V
C115 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C116 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C119 1-126-968-11 ELECT 100uF 20% 50V (AUS)
C119 1-128-576-11 ELECT 100uF 20% 63V
(US, CND)
C120 1-126-968-11 ELECT 100uF 20% 50V (AUS)
C120 1-128-576-11 ELECT 100uF 20% 63V
(US, CND)
C123 1-165-621-91 CERAMIC CHIP 0.1uF 50V
LOW AMPKEY POWERKEY CDJACKHI AMP
