– 57 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< JACK >
JK901 1-784-353-11 JACK (DIN)(SPEAKER L)
JK902 1-784-353-11 JACK (DIN)(SPEAKER R)
< CONNECTOR >
M501 1-564-234-11 PLUG, CONNECTOR (PIN CONTACT)8P
* M901 1-766-720-21 CONNECTOR, BOARD TO BOARD 17P
M902 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< TRANSISTOR >
Q486 8-729-201-53 TRANSISTOR 2SA1015-GR
Q487 8-729-231-55 TRANSISTOR 2SC2878-AB
Q488 8-729-231-55 TRANSISTOR 2SC2878-AB
Q501 8-729-281-53 TRANSISTOR 2SC1815-GR
Q502 8-729-201-53 TRANSISTOR 2SA1015-GR
Q503 8-729-201-53 TRANSISTOR 2SA1015-GR
Q504 8-729-209-15 TRANSISTOR 2SD2012
Q505 4-997-377-01 ISOLATION FILM
Q505 8-729-017-51 TRANSISTOR 2SB632K-E
Q506 8-729-281-53 TRANSISTOR 2SC1815-GR
Q507 4-997-377-01 ISOLATION FILM
Q507 8-729-188-23 TRANSISTOR 2SD882-P
Q508 4-997-377-01 ISOLATION FILM
Q508 8-729-188-23 TRANSISTOR 2SD882-P
Q509 4-997-377-01 ISOLATION FILM
Q509 8-729-188-23 TRANSISTOR 2SD882-P
Q510 8-729-017-51 TRANSISTOR 2SB632K-E
Q511 8-729-201-53 TRANSISTOR 2SA1015-GR
Q512 8-729-265-52 TRANSISTOR 2SC2655
< RESISTOR >
R457 1-247-863-91 CARBON 22K 5% 1/4W
R458 1-247-863-91 CARBON 22K 5% 1/4W
R461 1-249-429-11 CARBON 10K 5% 1/4W
R462 1-249-429-11 CARBON 10K 5% 1/4W
R463 1-247-895-91 CARBON 470K 5% 1/4W
R464 1-247-895-91 CARBON 470K 5% 1/4W
R465 1-249-425-11 CARBON 4.7K 5% 1/4W F
R466 1-247-815-91 CARBON 220 5% 1/4W
R467 1-249-429-11 CARBON 10K 5% 1/4W
R468 1-249-429-11 CARBON 10K 5% 1/4W
R469 1-249-429-11 CARBON 10K 5% 1/4W
R470 1-249-425-11 CARBON 4.7K 5% 1/4W F
R471 1-249-417-11 CARBON 1K 5% 1/4W F
R472 1-249-417-11 CARBON 1K 5% 1/4W F
R477 1-249-441-11 CARBON 100K 5% 1/4W
R478 1-249-441-11 CARBON 100K 5% 1/4W
R479 1-249-426-11 CARBON 5.6K 5% 1/4W
R480 1-249-426-11 CARBON 5.6K 5% 1/4W
R481 1-249-430-11 CARBON 12K 5% 1/4W
R482 1-249-430-11 CARBON 12K 5% 1/4W
R483 1-249-417-11 CARBON 1K 5% 1/4W F
R484 1-249-417-11 CARBON 1K 5% 1/4W F
R485A 1-249-429-11 CARBON 10K 5% 1/4W
R486A 1-249-429-11 CARBON 10K 5% 1/4W
R491 1-247-843-11 CARBON 3.3K 5% 1/4W
R492 1-247-843-11 CARBON 3.3K 5% 1/4W
R493 1-249-437-11 CARBON 47K 5% 1/4W
R494 1-249-437-11 CARBON 47K 5% 1/4W
R495 1-249-425-11 CARBON 4.7K 5% 1/4W F
R496 1-249-425-11 CARBON 4.7K 5% 1/4W F
R497 1-249-441-11 CARBON 100K 5% 1/4W
R498 1-249-441-11 CARBON 100K 5% 1/4W
R499 1-247-895-91 CARBON 470K 5% 1/4W
! R501 1-213-044-51 FUSIBLE 2.2 5% 1W F
! R502 1-212-946-11 FUSIBLE 3.3 5% 1/2W F
R503 1-249-429-11 CARBON 10K 5% 1/4W
R504 1-249-421-11 CARBON 2.2K 5% 1/4W F
R505 1-247-863-91 CARBON 22K 5% 1/4W
R506 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-249-437-11 CARBON 47K 5% 1/4W
R508 1-249-437-11 CARBON 47K 5% 1/4W
R509 1-247-807-31 CARBON 100 5% 1/4W
! R510 1-215-869-11 METAL OXIDE 1K 5% 1W F
R511 1-247-863-91 CARBON 22K 5% 1/4W
R512 1-249-431-11 CARBON 15K 5% 1/4W
! R514 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
! R515 1-213-048-00 FUSIBLE 3.3 5% 1W F
R516 1-249-413-11 CARBON 470 5% 1/4W F
! R517 1-213-064-51 FUSIBLE 15 5% 1W F
R518 1-249-413-11 CARBON 470 5% 1/4W F
! R519 1-212-946-11 FUSIBLE 3.3 5% 1/2W F
R520 1-249-413-11 CARBON 470 5% 1/4W F
R521 1-249-413-11 CARBON 470 5% 1/4W F
R524 1-249-381-11 CARBON 1 5% 1/4W F
R525 1-247-887-00 CARBON 220K 5% 1/4W
R526 1-249-441-11 CARBON 100K 5% 1/4W
R527 1-249-441-11 CARBON 100K 5% 1/4W
R528 1-249-425-11 CARBON 4.7K 5% 1/4W F
R529 1-249-437-11 CARBON 47K 5% 1/4W
< RELAY >
RL501 1-755-242-11 RELAY
**************************************************************
MISCELLANEOUS
*************
13 1-783-091-11 WIRE (FLAT TYPE)
52 1-693-400-21 FM/AM TUNER (AEP,UK,EE,CIS)
52 1-693-400-31 FM/AM TUNER (US,CND)
52 1-693-400-41 FM/AM TUNER (MY,SP,HK)
! 54 1-551-478-00 CORD, POWER (POLAR.SPT-2)(US,CND)
! 54 1-555-750-00 CORD, POWER (AEP,EE,CIS,MY,SP,HK)
! 54 1-751-535-11 CORD, POWER (UK)
! 63 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
65 1-501-659-11 ANTTENA (FM) (US,CND,MY,SP,HK)
66 1-501-985-11 LEAD, ANTTENA (AEP,UK,EE,CIS)
104 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK,EE,CIS)
104 1-751-688-11 WIRE (FLAT TYPE) (13 CORE)
(US,CND,MY,SP,HK)
110 1-759-548-11 DECK, MECHANICAL
151 1-759-548-11 DECK, MECHANICAL
! 201 8-848-387-01 OPTICAL PICK-UP KSS-213BA/S-N
VOL/POWER
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
