– 7 –
2-3. BO
TTOM CO
VER AND FR
ONT P
ANEL BLOCK
2-4. DOOR CO
VER ASSY AND MECHANICAL DECK (CASSETTE)
1
Two screws
(BVTP 3x8)
2
Two screws
(BVTP 3x8)
3
Bottom cove
r
4
Two claws
5
Front panel block
4
Four screws
(BVTP 3x10)
5
Mechanical dec
k
(cassette)
1
Open the Door cover ASSY. (Push the
A
portion.)
2
Door cover assy
3
Door spring
A
6
8
