7-24. PRINTED WIRING BOARD – I/O SECTION (SIDE A) –
• See page 29 for Circuit Boards Location. :Uses unleaded solder.
• Semiconductor
Location
Ref. No.
Location
IC201 B-6 IC203 B-5 IC204 B-5 IC601 B-4 IC602 B-3 IC608 B-3 Q603 B-4 Q604 B-4
