7-32. PRINTED WIRING BOARD – MIB01 POWER SECTION –
• See page 29 for Circuit Boards Location. :Uses unleaded solder.
• Semiconductor
Location
Ref. No.
Location
D9021 C-2 D9022 C-4 D9023 C-4 IC901 A-2 IC902 A-3
7-33. SCHEMATIC DIAGRAM – MIB01 POWER SECTION –
IC902
IC901
13
12
16
(CHASSIS)
(CHASSIS)
12
A B
C
34
N
MAIN
BOARD
CNP301
(Page 46)
M
MIB01
BOARD
CN5101
(Page 62)
66
50
L9023
D9021
L9021
C906
IC901
C908
C911
C910
D9022
R902 R903
TK9002
TK9001
D9023
C907
IC902
C909
C905
L9024 L9022
C912
C913
CN9001
CN9002
RK16
220 50V
SI-8050JD-TP
100 10V
100 10V100
10V
10EDB40
1.8k 82
11EQS04
470 16V
TA48033F-TE16L
0.01
0.47
0.01
0.47
2P
6P
