SERVICE MANUAL
Sony Corporation
Home Audio Division
Published by Sony Engineering Corporation
SS-CT46/GS24/TS46/
TS46B/WS42
US Model
Canadian Model
AEP Model
UK Model
SS-CT46/GS24/TS46/TS46B/WS42
E Model
Australian Model
SS-CT46/TS46B/WS42
SUBWOOFER/SPEAKER SYSYTEM
• SS-GS24 is the package speaker in DAV-DZ500F/
DZ500KF/FX100W/DZ700FW.
• SS-GS24 is composed of following models.
SPECIFICATIONS
Ver. 1.2 2005.12
Front (SS-TS46)
Speaker system Two-way Bass reflex,
magnetically shielded
Speaker unit 70 × 100 mm cone type,
25 mm dia. balanced dome
type
Rated impedance 2.7 ohms
Dimensions (approx.) 265 × 1,108 × 265 mm
(w/h/d)
Mass (approx.) 3.6 kg
Center (SS-CT46)
Speaker system Two-way Bass reflex,
magnetically shielded
Speaker unit 55 × 110 mm cone type,
25 mm dia. balanced dome
type
Rated impedance 2.7 ohms
Dimensions (approx.) 300 × 79 × 116 mm
(w/h/d)
Mass (approx.) 1.2 kg
Surround (SS-TS46B)
Speaker system Two-way Bass reflex
Speaker unit 70 × 100 mm cone type,
25 mm dia. balanced dome
type
Rated impedance 2.7 ohms
Dimensions (approx.) 265 × 1,108 × 265 mm
(w/h/d)
Mass (approx.) 3.4 kg
Subwoofer (SS-WS42)
Speaker system Bass reflex, magnetically
shielded
Speaker unit 200 mm cone type
Rated impedance 1.3 ohms
Dimensions (approx.) 206 × 382 × 392 mm
(w/h/d)
Mass (approx.) 7.8 kg
Design and specifications are subject to change
without notice.
9-879-632-03
2005L16-1
© 2005.12
SS-GS24
FRONT speaker SS-TS46
CENTER speaker SS-CT46
SURROUND speaker SS-TS46B
SUBWOOFER SS-WS42
SS-WS42 SS-TS46
SS-TS46B
SS-CT46
• SS-GS24 is the speaker section in DAV-DZ500F/
DZ500KF/FX100W/DZ700FW.
• SS-CT46 is the center speaker in DAV-DZ500F/
DZ500KF/DZ700FW/FX80/FX100W/FX888K/
FX999W/FX1000W.
• SS-TS46 is the front speaker in DAV-DZ500F/
DZ500KF/DZ700FW/FX80/FX100W.
• SS-TS46B is the surround speaker in DAV-
DZ500F/DZ500KF/DZ700FW/FX100W/FX999W /
FX1000W.
• SS-WS42 is the speaker section in DAV-DZ500F/
DZ500KF/DZ550/DZ700FW/DZ770W/FX10/FX80
/FX100W.
