Sony HCD-FX100W - Page 32

24
TA-WR2
Ref. No. Part No. Description Remark
R270 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R271 1-216-849-11 METAL CHIP 220K 5% 1/10W
R283 1-216-841-11 METAL CHIP 47K 5% 1/10W
R284 1-216-864-11 SHORT CHIP 0
< TERMINAL BOARD >
T100 1-780-281-11 TERMINAL BOARD (SP) (2P)
< VIBRATOR >
X101 1-795-485-21 VIBRATOR, CRYSTAL 12.288MHz(SMD)
X102 1-795-313-21 VIBRATOR, CERAMIC 8MHz
X103 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
************************************************************
SWITCH BOARD
*************
< CONNECTOR >
* CN901 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0 S901 1-571-433-31 SWITCH, PUSH (AC POWER)(POWER)
************************************************************
MISCELLANEOUS
**************
53 1-787-331-11 FAN, D.C.
0 54 1-696-847-22 CORD, POWER (AUS)
0 54 1-783-531-91 CORD, POWER (US, CND)
0 54 1-824-090-11 CORD, POWER (MX)
0 54 1-828-528-11 CORD, POWER (AEP, UK, RU, E3, SP)
0 54 1-828-529-21 CORD, POWER (KR)
0 F901 1-532-465-33 FUSE (T3.15AL/250V)(EXCEPT US, CND, MX)
0 F901 1-533-420-12 FUSE, GLASS TUBE (DIA.5)(5A/125V)(MX)
0 F901 1-533-453-12 FUSE, GLASS TUBE (DIA.5)(T5AL/125V)
(US, CND)
SWITCHRX
Ver. 1.2
