105
HCD-FX100W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
H/P BOARD
*********
< CAPACITOR >
C862 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C866 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C870 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C872 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C873 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< DIODE >
D824 8-719-988-61 DIODE 1SS355TE-17
D825 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL BOARD >
EB802 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB811 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB812 1-500-284-21 INDUCTOR, FERRITE BEAD
FB813 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB814 1-216-295-91 SHORT CHIP 0
< JACK >
J801 1-566-891-21 JACK (PHONES)
< FERRITE BEAD/SHORT >
L811 1-216-864-11 SHORT CHIP 0
L812 1-469-144-21 FERRITE, EMI (SMD) (2012)
L813 1-216-864-11 SHORT CHIP 0
L814 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q806 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q807 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q808 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q809 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
< RESISTOR >
R861 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R862 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R863 1-216-801-11 METAL CHIP 22 5% 1/10W
R864 1-216-801-11 METAL CHIP 22 5% 1/10W
R865 1-216-805-11 METAL CHIP 47 5% 1/10W
R866 1-216-805-11 METAL CHIP 47 5% 1/10W
R867 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R868 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R869 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R870 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
************************************************************
A-1111-088-A I/O BOARD, COMPLETE
*******************
< CAPACITOR >
C102 1-126-933-11 ELECT 100uF 20% 16V
C103 1-124-234-00 ELECT 22uF 20% 16V
C104 1-124-234-00 ELECT 22uF 20% 16V
C109 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C203 1-125-972-91 ELECT 100uF 20% 16V
C204 1-124-247-91 ELECT 10uF 20% 35V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-124-261-00 ELECT 10uF 20% 25V
C207 1-124-247-91 ELECT 10uF 20% 35V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-176-11 ELECT 220uF 20% 10V
C211 1-124-247-91 ELECT 10uF 20% 35V
C212 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C215 1-115-156-11 CERAMIC CHIP 1uF 10V
C216 1-115-156-11 CERAMIC CHIP 1uF 10V
C217 1-125-972-91 ELECT 100uF 20% 16V
C218 1-115-156-11 CERAMIC CHIP 1uF 10V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C220 1-124-247-91 ELECT 10uF 20% 35V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-933-11 ELECT 100uF 20% 16V
C228 1-126-933-11 ELECT 100uF 20% 16V
C231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C600 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-126-933-11 ELECT 100uF 20% 16V
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-124-234-00 ELECT 22uF 20% 16V
C608 1-125-972-91 ELECT 100uF 20% 16V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-124-234-00 ELECT 22uF 20% 16V
C611 1-124-234-00 ELECT 22uF 20% 16V
C612 1-104-662-91 ELECT 22uF 20% 25V
C613 1-104-662-91 ELECT 22uF 20% 25V
C614 1-104-662-91 ELECT 22uF 20% 25V
C615 1-126-160-11 ELECT 1uF 20% 50V
C616 1-126-160-11 ELECT 1uF 20% 50V
C617 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C622 1-124-234-00 ELECT 22uF 20% 16V
C623 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C624 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C626 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C658 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C661 1-126-933-11 ELECT 100uF 20% 16V
C663 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C665 1-125-972-91 ELECT 100uF 20% 16V
C666 1-164-156-11 CERAMIC CHIP 0.1uF 25V
I/OH/P
