107
HCD-FX100W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S802 1-786-763-11 SWITCH, TACTILE (VOLUME +)
S804 1-786-763-11 SWITCH, TACTILE (FUNCTION)
S805 1-786-763-11 SWITCH, TACTILE (X)
S806 1-786-763-11 SWITCH, TACTILE (x)
S807 1-786-763-11 SWITCH, TACTILE (>)
S808 1-786-763-11 SWITCH, TACTILE (VOLUME –)
************************************************************
LED BOARD
*********
< CONNECTOR >
CN803 1-784-867-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D811 8-719-079-89 DIODE SML-020MDT-T86 (DISC1)
D812 8-719-079-89 DIODE SML-020MDT-T86 (DISC2)
D813 8-719-079-89 DIODE SML-020MDT-T86 (DISC3)
D814 8-719-079-89 DIODE SML-020MDT-T86 (DISC4)
D815 8-719-079-89 DIODE SML-020MDT-T86 (DISC5)
< RESISTOR >
R822 1-216-817-11 METAL CHIP 470 5% 1/10W
R823 1-216-817-11 METAL CHIP 470 5% 1/10W
R824 1-216-817-11 METAL CHIP 470 5% 1/10W
R825 1-216-817-11 METAL CHIP 470 5% 1/10W
R826 1-216-817-11 METAL CHIP 470 5% 1/10W
R827 1-216-817-11 METAL CHIP 470 5% 1/10W
R828 1-216-817-11 METAL CHIP 470 5% 1/10W
R829 1-216-817-11 METAL CHIP 470 5% 1/10W
R830 1-216-817-11 METAL CHIP 470 5% 1/10W
R831 1-216-817-11 METAL CHIP 470 5% 1/10W
R833 1-216-821-11 METAL CHIP 1K 5% 1/10W
R834 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R835 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R836 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R837 1-216-833-11 METAL CHIP 10K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S809 1-786-763-11 SWITCH, TACTILE (H)
S810 1-786-763-11 SWITCH, TACTILE (A)
S811 1-786-763-11 SWITCH, TACTILE (DISC5)
S812 1-786-763-11 SWITCH, TACTILE (DISC4)
S813 1-786-763-11 SWITCH, TACTILE (DISC3)
S814 1-786-763-11 SWITCH, TACTILE (DISC2)
S815 1-786-763-11 SWITCH, TACTILE (DISC1)
S816 1-786-763-11 SWITCH, TACTILE (?/1)
************************************************************
A-1111-081-A MAIN BOARD, COMPLETE
********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C101 1-164-346-11 CERAMIC CHIP 1uF 16V
C102 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-164-346-11 CERAMIC CHIP 1uF 16V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C109 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C110 1-163-205-00 CERAMIC CHIP 0.001uF 10% 50V
C111 1-164-346-11 CERAMIC CHIP 1uF 16V
C112 1-164-346-11 CERAMIC CHIP 1uF 16V
C115 1-164-346-11 CERAMIC CHIP 1uF 16V
C116 1-164-346-11 CERAMIC CHIP 1uF 16V
C117 1-164-346-11 CERAMIC CHIP 1uF 16V
C119 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C120 1-126-947-11 ELECT 47uF 20% 35V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C135 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C136 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C137 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C145 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C146 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C147 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C151 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C152 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C155 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C156 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C157 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C161 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C162 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C165 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C166 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C167 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C171 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C172 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C175 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C176 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C177 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C181 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C182 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C185 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C186 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C187 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C188 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C189 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C191 1-107-898-11 ELECT 2200uF 20% 35V
C192 1-107-898-11 ELECT 2200uF 20% 35V
C195 1-107-898-11 ELECT 2200uF 20% 35V
C196 1-107-898-11 ELECT 2200uF 20% 35V
C197 1-107-898-11 ELECT 2200uF 20% 35V
C199 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C202 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C203 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C204 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C209 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C210 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
MAINLEDKEY
