Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-FX200/FX205
4141
POWER-TR PT
R860 1-216-805-11 METAL CHIP 47 5% 1/10W
R865 1-216-809-11 METAL CHIP 100 5% 1/10W
R866 1-216-809-11 METAL CHIP 100 5% 1/10W
R870 1-216-821-11 METAL CHIP 1K 5% 1/10W
R871 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R872 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R873 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R880 1-216-833-11 METAL CHIP 10K 5% 1/10W
R885 1-216-833-11 METAL CHIP 10K 5% 1/10W
R886 1-216-845-11 METAL CHIP 100K 5% 1/10W
R887 1-216-845-11 METAL CHIP 100K 5% 1/10W
R888 1-216-845-11 METAL CHIP 100K 5% 1/10W
R889 1-216-841-11 METAL CHIP 47K 5% 1/10W
(RU, E2, E51, EA, SP, TW, AR, KR, TH, AUS)
R891 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E2, E51, AR)
R891 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, EA, SP, TW, TH, AUS)
R891 1-216-839-11 METAL CHIP 33K 5% 1/10W
(KR)
R892 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP, RU)
R892 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(SP, TW, TH)
R892 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EA)
R892 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AUS)
R892 1-216-841-11 METAL CHIP 47K 5% 1/10W
(E2, E51, AR)
R892 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KR)
R894 1-216-845-11 METAL CHIP 100K 5% 1/10W
R895 1-216-839-11 METAL CHIP 33K 5% 1/10W
R896 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R897 1-216-847-11 METAL CHIP 150K 5% 1/10W
R981 1-216-864-11 SHORT CHIP 0
R986 1-216-809-11 METAL CHIP 100 5% 1/10W
R988 1-216-809-11 METAL CHIP 100 5% 1/10W
R989 1-216-821-11 METAL CHIP 1K 5% 1/10W
R990 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R991 1-216-864-11 SHORT CHIP 0
< SWITCH/ROTARY ENCODER >
S820 1-771-410-21 SWITCH, TACTILE (– TUNE, l m)
S821 1-771-410-21 SWITCH, TACTILE (TUNE +, M L)
S822 1-771-410-21 SWITCH, TACTILE (ENTER)
S823 1-771-410-21 SWITCH, TACTILE (–
)
S824 1-771-410-21 SWITCH, TACTILE (
+)
S830 1-771-410-21 SWITCH, TACTILE (FUNCTION)
S831 1-771-410-21 SWITCH, TACTILE (DSGX)
S832 1-771-410-21 SWITCH, TACTILE (u)
S833 1-771-410-21 SWITCH, TACTILE (CANCEL, x)
S840 1-771-410-21 SWITCH, TACTILE (
?/1
)
S850 1-480-469-11 ENCODER, ROTARY
< VIBRATOR >
X801 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X802 1-814-399-11 VIBRATOR, CERAMIC (15MHz)
*************************************************************
POWER-TR BOARD
****************
< TRANSISTOR >
Q915 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q940 8-729-024-93 TRANSISTOR 2SB1565E
< RESISTOR >
R915 1-216-833-11 METAL CHIP 10K 5% 1/10W
R957 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
PT BOARD (AEP, RU, SP, TW, AR, KR, TH, AUS)
********
< CAPACITOR >
0 C001 1-113-924-91 CERAMIC 0.0047uF 20% 250V
(AEP, RU, KR)
C905 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
CN004 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D001 6-502-961-01 DIODE DA2J10100L
D925 6-501-582-01 DIODE 1N4002-A2
D926 6-501-582-01 DIODE 1N4002-A2
D927 6-501-582-01 DIODE 1N4002-A2
D928 6-501-582-01 DIODE 1N4002-A2
< FUSE HOLDER >
FH001 1-533-217-31 FUSE HOLDER (TW)
FH002 1-533-217-31 FUSE HOLDER (TW)
FH003 1-533-217-31 FUSE HOLDER (AEP, RU, SP, AR, KR, TH, AUS)
FH004 1-533-217-31 FUSE HOLDER (AEP, RU, SP, AR, KR, TH, AUS)
< LINE FILTER >
0 LF001 1-443-993-11 TRANSFORMER, LINE FILTER (LFT)
(AEP, RU, KR)
< RELAY >
0 RY001 1-755-334-11 RELAY, AC POWER
< TRANSFORMER >
0 T002 1-443-912-11 TRANSFORMER, POWER (AEP, RU, AR, KR, TH)
0 T004 1-445-105-11 TRANSFORMER, POWER (SP, TW, AUS)
*************************************************************
PT-SW BOARD (E2, E51, EA)
************
< CAPACITOR >
C905 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
CN004 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D001 6-502-961-01 DIODE DA2J10100L
D925 6-501-582-01 DIODE 1N4002-A2
PANEL
Ver. 1.1
PT-SW
