Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-FX200/FX205
42
D926 6-501-582-01 DIODE 1N4002-A2
D927 6-501-582-01 DIODE 1N4002-A2
D928 6-501-582-01 DIODE 1N4002-A2
< FUSE HOLDER >
FH001 1-533-217-31 FUSE HOLDER
FH002 1-533-217-31 FUSE HOLDER
FH003 1-533-217-31 FUSE HOLDER
FH004 1-533-217-31 FUSE HOLDER
< RELAY >
0 RY002 1-755-496-11 RELAY
< SWITCH >
0 S001 1-786-404-11 SELECTOR, VOLTAGE (SWS-2201)
(VOLTAGE SELECTOR)
< TRANSFORMER >
0 T004 1-445-105-11 TRANSFORMER, POWER
*************************************************************
REG BOARD
**********
< TRANSISTOR >
Q930 8-729-024-93 TRANSISTOR 2SB1565E
Q934 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
< RESISTOR >
R947 1-216-833-11 METAL CHIP 10K 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
A-1754-831-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-165-492-21 ELECT CHIP 100uF 20% 10V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C104 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-126-961-11 ELECT 2.2uF 20% 50V
C108 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-104-658-91 ELECT 100uF 20% 10V
C113 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C114 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C120 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C121 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C122 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C127 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C128 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN102 1-784-871-51 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
CN105 1-822-423-11 CONNECTOR, USB (A) (
)
CN106 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN108 1-784-834-51 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
< DIODE >
D100 6-501-579-01 DIODE MC2837
D101 6-501-579-01 DIODE MC2837
D102 6-501-579-01 DIODE MC2837
< IC >
IC101 (Not supplied) IC LC87F1JJ2AU-SQFP-H
< COIL >
L101 1-457-223-11 COMMON MODE CHOKE COIL
< RESISTOR >
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-857-11 METAL CHIP 1M 5% 1/10W
R108 1-216-817-11 METAL CHIP 470 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-809-11 METAL CHIP 100 5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-845-11 METAL CHIP 100K 5% 1/10W
R119 1-216-864-11 SHORT CHIP 0
R120 1-216-803-11 METAL CHIP 33 5% 1/10W
R121 1-216-803-11 METAL CHIP 33 5% 1/10W
R122 1-216-835-11 METAL CHIP 15K 5% 1/10W
R123 1-216-835-11 METAL CHIP 15K 5% 1/10W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-809-11 METAL CHIP 100 5% 1/10W
R133 1-216-809-11 METAL CHIP 100 5% 1/10W
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-833-11 METAL CHIP 10K 5% 1/10W
R137 1-216-833-11 METAL CHIP 10K 5% 1/10W
R138 1-216-295-91 SHORT CHIP 0
R139 1-216-295-91 SHORT CHIP 0
R140 1-216-295-91 SHORT CHIP 0
R141 1-216-864-11 SHORT CHIP 0
R143 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-654-21 VIBRATOR, CRYSTAL (12MHz)
************************************************************
PT-SW REG USB
Note: IC101 cannot exchange with single. When this part is damaged,
exchange the entire mounted board.
Ver. 1.1
