Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-G2BNiP/G2NiP
7373
D956 6-500-334-01 DIODE MC2836-T112-1
D957 6-502-969-01 DIODE DZ2J06800L
D958 6-503-022-01 DIODE DZ2J100M0L
D959 6-502-969-01 DIODE DZ2J06800L
D961 6-500-334-01 DIODE MC2836-T112-1
< FUSE >
0 F951 1-532-504-33 FUSE (T 4 AL/250 V)
< FUSE HOLDER >
0 FH951 1-533-217-41 FUSE HOLDER
0 FH952 1-533-217-41 FUSE HOLDER
< IC >
IC951 6-716-554-11 IC BD9329AEFJ-E2
IC952 6-716-554-11 IC BD9329AEFJ-E2
IC953 6-716-554-11 IC BD9329AEFJ-E2
< COIL >
L951 1-424-918-21 COIL, CHOKE (SMD) 10uH
L952 1-424-918-21 COIL, CHOKE (SMD) 10uH
L953
1-424-918-21 COIL, CHOKE (SMD) 10uH
L954 1-460-402-11 COMMON MODE CHOKE COIL
L956 1-460-402-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q951 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
< RESISTOR >
R951 1-216-295-91 SHORT CHIP 0
R952 1-216-864-11 SHORT CHIP 0
R953 1-216-864-11 SHORT CHIP 0
R954 1-216-864-11 SHORT CHIP 0
R955 1-216-839-11 METAL CHIP 33K 5% 1/10W
R956 1-216-834-11 METAL CHIP 12K 5% 1/10W
R957 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R958 1-216-801-11 METAL CHIP 22 5% 1/10W
R959 1-216-801-11 METAL CHIP 22 5% 1/10W
R960 1-216-801-11 METAL CHIP 22 5% 1/10W
R961 1-216-801-11 METAL CHIP 22 5% 1/10W
R962 1-216-801-11 METAL CHIP 22 5% 1/10W
R963 1-216-801-11 METAL CHIP 22 5% 1/10W
R964 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R965 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R966 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R967 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R968 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R969 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R970 1-211-989-11 METAL CHIP 68 0.5% 1/10W
R971 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R972 1-216-864-11 SHORT CHIP 0
R973 1-216-864-11 SHORT CHIP 0
R974 1-216-864-11 SHORT CHIP 0
R975 1-216-821-11 METAL CHIP 1K 5% 1/10W
R976 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R977 1-216-864-11 SHORT CHIP 0
R978 1-216-821-11 METAL CHIP 1K 5% 1/10W
R979 1-216-821-11 METAL CHIP 1K 5% 1/10W
R980 1-216-821-11 METAL CHIP 1K 5% 1/10W
R981 1-216-821-11 METAL CHIP 1K 5% 1/10W
R982 1-216-821-11 METAL CHIP 1K 5% 1/10W
R983 1-216-841-11 METAL CHIP 47K 5% 1/10W
R988 1-216-864-11 SHORT CHIP 0
R989 1-216-864-11 SHORT CHIP 0
R992 1-216-833-11 METAL CHIP 10K 5% 1/10W
R993 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
*************************************************************
FL-NET BOARD
************
4-154-640-01 SHEET (FL HOLDER), ADHESIVE
< CAPACITOR >
C4101 1-124-234-00 ELECT 22uF 20% 16V
C4103 1-136-153-00 FILM 0.01uF 5% 50V
C4104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C4105 1-128-131-11 ELECT 22uF 20% 50V
C4106 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C4107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C4108 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C4110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4111 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4112 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4113 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4114 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4115 1-124-234-00 ELECT 22uF 20% 16V
C4119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4120 1-125-972-91 ELECT 100uF 20% 16V
C4121 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C4123 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C4125 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C4126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4127 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4128 1-128-131-11 ELECT 22uF 20% 50V
< CONNECTOR >
CN4102 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN4108 1-779-287-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
< DIODE >
D4101 6-500-334-01 DIODE MC2836-T112-1
D4102 6-500-335-01 DIODE MC2838-T112-1
D4103 6-502-970-01 DIODE DZ2J068M0L
D4107 8-719-056-11 LED SML72423C-TP15 (STANDBY)
< COIL >
L4101 1-412-537-31 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND4102 1-811-488-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q4101 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q4102 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4103 8-729-038-30 TRANSISTOR RT1P141M-TP-1
Q4104 8-729-038-30 TRANSISTOR RT1P141M-TP-1
< RESISTOR >
R4101 1-216-295-91 SHORT CHIP 0
DCDC FL-NET
