Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-G2BNiP/G2NiP
74
R4102 1-218-446-11 METAL CHIP 1 5% 1/10W
R4103 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R4104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4105 1-216-809-11 METAL CHIP 100 5% 1/10W
R4106 1-216-809-11 METAL CHIP 100 5% 1/10W
R4107 1-216-846-11 METAL CHIP 120K 5% 1/10W
R4108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4109 1-216-864-11 SHORT CHIP 0
R4110 1-216-864-11 SHORT CHIP 0
R4111 1-216-864-11 SHORT CHIP 0
R4112 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4113 1-216-840-11 METAL CHIP 39K 5% 1/10W
R4114 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4115 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4117 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4120 1-216-810-11 METAL CHIP 120 5% 1/10W
R4121 1-216-864-11 SHORT CHIP 0
R4122 1-216-864-11 SHORT CHIP 0
R4123 1-216-864-11 SHORT CHIP 0
R4124 1-216-864-11 SHORT CHIP 0
R4125 1-216-864-11 SHORT CHIP 0
R4126 1-216-864-11 SHORT CHIP 0
R4127 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4128 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4129 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4131 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4133 1-216-807-11 METAL CHIP 68 5% 1/10W
R4135 1-216-797-11 METAL CHIP 10 5% 1/10W
R4136 1-216-797-11 METAL CHIP 10 5% 1/10W
R4137 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4138 1-216-864-11 SHORT CHIP 0
< SWITCH >
S4101 1-762-875-21 SWITCH, KEYBOARD (
?
/1)
S4102 1-762-875-21 SWITCH, KEYBOARD (Z)
S4103 1-762-875-21 SWITCH, KEYBOARD (x)
S4104 1-762-875-21 SWITCH, KEYBOARD (u)
S4105 1-762-875-21 SWITCH, KEYBOARD (M L, TUNE +)
S4106 1-762-875-21 SWITCH, KEYBOARD (l m, TUNE –)
S4107 1-762-875-21 SWITCH, KEYBOARD (M)
S4108 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S4109 1-762-875-21 SWITCH, KEYBOARD (m)
S4110 1-762-875-21 SWITCH, KEYBOARD (BACK)
S4111 1-762-875-21 SWITCH, KEYBOARD (OPTIONS)
< TRANSFORMER >
T4101 1-697-130-11 TRANSFORMER, DC-DC CONVERTER
*************************************************************
A-1820-897-A HP BOARD, COMPLETE
*******************
< CAPACITOR >
C1501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
JOG2JOG1FL-NET HP
< DIODE >
D4201 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB1501 1-481-348-21 EMI FERRITE (SMD) (1608)
FB2501 1-481-348-21 EMI FERRITE (SMD) (1608)
FB4201 1-481-348-21 EMI FERRITE (SMD) (1608)
< JACK >
J4201 1-842-698-11 JACK (PHONES)
< JUMPER RESISTOR >
R4202 1-216-864-11 SHORT CHIP 0
*************************************************************
JOG1 BOARD
***********
< CAPACITOR >
C4301 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4302 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4301 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< IC >
IC4301 6-600-768-01 IC PNA4823M03S0
< RESISTOR >
R4305 1-216-825-11 METAL CHIP
2.2K 5% 1/10W
R4306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4307 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4309 1-216-805-11 METAL CHIP 47 5% 1/10W
R4310 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4311 1-216-809-11 METAL CHIP 100 5% 1/10W
R4312 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4313 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4316 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4317 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< ROTARY ENCODER >
S4301 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
S4302 1-489-832-11 ENCODER, ROTARY (FUNCTION)
*************************************************************
JOG2 BOARD
***********
< RESISTOR >
R4321 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4323 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4325 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4326 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4327 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4328 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
Ver. 1.1
Note: When replacing the rotary encoder (Ref. No.
S4301 (JOG1 board), S4321 and S4322 (JOG2
board)), replace the three parts at the same time.
