Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-G2BNiP/G2NiP
7575
< ROTARY ENCODE >
S4321 1-418-725-51 ENCODER, ROTARY (12 TYPE) (TONE TREBLE)
S4322 1-418-725-51 ENCODER, ROTARY (12 TYPE) (TONE BASS)
*************************************************************
LAN BOARD
**********
< CAPACITOR >
C1036 1-114-472-91 CERAMIC CHIP 0.001uF 10% 2KV
C1037 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< MODULAR JACK >
CN1006 1-842-235-11 JACK, MODULAR (NETWORK
)
< JUMPER RESISTOR >
JR1031 1-216-864-11 SHORT CHIP 0
R1064 1-216-864-11 SHORT CHIP 0
R1065 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1823-064-A MAIN BOARD, COMPLETE (G2NiP)
A-1823-068-A MAIN BOARD, COMPLETE (G2BNiP: AEP, UK)
A-1847-083-A MAIN BOARD, COMPLETE (G2BNiP: AUS)
********************
< CAPACITOR >
C401 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C402 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C405 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C406 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C411 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C412 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C413 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C414 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C415 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C416 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C417 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C419 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(G2BNiP)
C420 1-100-582-21 ELECT CHIP 470uF 20% 4V
C602 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C607 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C608 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C609 1-117-681-11 ELECT CHIP 100uF 20% 16V
C610 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C612 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C613 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C614 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C615 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C617 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C622 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C623 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C626 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C627 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C726 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C727 1-127-931-21 ELECT CHIP 470uF 20% 16V
C728 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C729 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C730 1-116-108-11 ELECT CHIP 330uF 20% 10V
C731 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C732 1-100-660-91 CERAMIC CHIP 1uF 10% 10V
C733 1-100-660-91 CERAMIC CHIP 1uF 10% 10V
C734 1-124-779-00 ELECT CHIP 10uF 20% 16V
C736 1-126-926-11 ELECT 1000uF 20% 10V
C737 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
(G2BNiP: AEP, UK/G2NiP)
C738 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
(G2BNiP: AEP, UK/G2NiP)
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(G2BNiP)
C802 1-124-779-00 ELECT CHIP 10uF 20% 16V
(G2BNiP)
C806 1-124-779-00 ELECT CHIP 10uF 20% 16V
C807 1-124-779-00 ELECT CHIP 10uF 20% 16V
C808 1-124-779-00 ELECT CHIP 10uF 20% 16V
C809 1-124-779-00 ELECT CHIP 10uF 20% 16V
C810 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C811 1-124-779-00 ELECT CHIP 10uF 20% 16V
C812 1-124-779-00 ELECT CHIP 10uF 20% 16V
C813 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C814 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C815 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C816 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C817 1-124-779-00 ELECT CHIP 10uF 20% 16V
C818 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C819 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C821 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C822 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C823 1-107-820-81 CERAMIC CHIP 0.1uF 16V
C825 1-124-779-00 ELECT CHIP 10uF 20% 16V
C829 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C830 1-107-820-81 CERAMIC CHIP 0.1uF 16V
C831 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C832 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C834 1-107-820-81 CERAMIC CHIP 0.1uF 16V
C835 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C836 1-100-053-21 ELECT CHIP 220uF 20% 6.3V
C838 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C839 1-128-994-21 ELECT CHIP 47uF 20% 10V
C840 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C841 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C849 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C851 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C855 1-124-779-00 ELECT CHIP 10uF 20% 16V
C856 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C857 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C858 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C859 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C860 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C861 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C862 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C865 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
JOG2 LAN MAIN
Ver. 1.1
Note: When replacing the rotary encoder (Ref. No.
S4301 (JOG1 board), S4321 and S4322 (JOG2
board)), replace the three parts at the same time.
To Next Page
