Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-G2BNiP/G2NiP
82
R5087 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R5088 1-218-990-81 SHORT CHIP 0
R5089 1-218-990-81 SHORT CHIP 0
R5090 1-218-990-81 SHORT CHIP 0
R5091 1-218-990-81 SHORT CHIP 0
R5092 1-218-990-81 SHORT CHIP 0
R5093 1-216-801-11 METAL CHIP 22 5% 1/10W
R5094 1-216-801-11 METAL CHIP 22 5% 1/10W
R5095 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R5096 1-216-864-11 SHORT CHIP 0
R5098 1-216-864-11 SHORT CHIP 0
R5099 1-216-864-11 SHORT CHIP 0
R5101 1-216-864-11 SHORT CHIP 0
R5102 1-216-864-11 SHORT CHIP 0
R5103 1-216-864-11 SHORT CHIP 0
R5104 1-216-864-11 SHORT CHIP 0
R5105 1-216-864-11 SHORT CHIP 0
R5106 1-216-864-11 SHORT CHIP 0
R5107 1-216-864-11 SHORT CHIP 0
R5108 1-216-864-11 SHORT CHIP 0
R5109 1-216-864-11 SHORT CHIP 0
R5110 1-216-864-11 SHORT CHIP 0
R5111 1-216-864-11 SHORT CHIP 0
R5112 1-216-864-11 SHORT CHIP 0
R5113 1-216-864-11 SHORT CHIP 0
R5114 1-216-864-11 SHORT CHIP 0
R5115 1-216-864-11 SHORT CHIP 0
R5116 1-216-864-11 SHORT CHIP 0
R5118 1-216-864-11 SHORT CHIP 0
R5119 1-216-864-11 SHORT CHIP 0
R5120 1-216-864-11 SHORT CHIP 0
R5121 1-218-285-11 METAL CHIP 75 5% 1/10W
R5122 1-218-285-11 METAL CHIP 75 5% 1/10W
R5123 1-216-797-11 METAL CHIP 10 5% 1/10W
R5126 1-216-864-11 SHORT CHIP 0
R5127 1-216-864-11 SHORT CHIP 0
R5128 1-218-929-11 METAL CHIP 10 5% 1/16W
R5129 1-218-929-11 METAL CHIP 10 5% 1/16W
R5131 1-218-929-11 METAL CHIP 10 5% 1/16W
R5132 1-218-965-11 METAL CHIP 10K 5% 1/16W
< TRANSFORMER >
T001 1-445-954-11 PULSE TRANSFORMER
*************************************************************
SUB-PT BOARD
************
< CAPACITOR >
C4401 1-126-963-11 ELECT 4.7uF 20% 50V
C4402 1-126-942-61 ELECT 1000uF 20% 25V
C4404 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C4405 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C4406 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C4407 1-113-924-51 CERAMIC 0.0047uF 20% 250V
C4408 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
0 CN4404 1-565-792-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
0 CN4405 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D4401 6-500-335-01 DIODE MC2838-T112-1
D4402 6-500-335-01 DIODE MC2838-T112-1
D4404 6-500-334-01 DIODE MC2836-T112-1
D4406 6-502-961-01 DIODE DA2J10100L
< FUSE >
0 F4401 1-532-504-33 FUSE (T 4 AL/250 V)
< FUSE HOLDER >
0 FH4401 1-533-217-41 FUSE HOLDER
0 FH4402 1-533-217-41 FUSE HOLDER
< TRANSISTOR >
Q4401 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R4402 1-216-864-11 SHORT CHIP 0
R4403 1-216-843-11 METAL CHIP 68K 5% 1/10W
R4404 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4406 1-216-864-11 SHORT CHIP 0
R4407 1-216-801-11 METAL CHIP 22 5% 1/10W
< RELAY >
0 RY4401 1-755-276-22 RELAY, POWER
< TRANSFORMER >
0 T4401 1-443-912-11 TRANSFORMER, POWER (G2BNiP: UK/G2NiP)
0 T4401 1-445-105-11 TRANSFORMER, POWER (G2BNiP: AUS)
0 T4402 1-445-048-21 TRANSFORMER, LINE FILTER
*************************************************************
A-1820-895-A TUNER BOARD, COMPLETE
**********************
< CAPACITOR >
C4501 1-124-584-00 ELECT 100uF 20% 6.3V
C4502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4505 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C4506 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C4507 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C4508 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C4511 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4512 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN4501 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN4503 1-842-376-11 CONNECTOR, FM ANTENNA
(ANTENNA FM 75 COAXIAL)
< DIODE >
D4501 6-500-848-01 DIODE MC2840-T112-1
D4502 6-500-848-01 DIODE MC2840-T112-1
D4503 6-500-848-01 DIODE MC2840-T112-1
< BAND PASS FILTER >
FL4501 1-236-711-21 FILTER, BAND PASS
TUNERSUB-PTNET
To Next Page
