Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-G2BNiP/G2NiP
8383
< IC >
IC4501 6-717-268-01 IC RZ5B800-0002E2
< JUMPER RESISTOR >
JR502 1-216-864-11 SHORT CHIP 0
< COIL >
L4501 1-457-998-11 COIL, AM ANTENNA
L4502 1-481-813-21 INDUCTOR
1uH
L4503 1-469-918-21 INDUCTOR 33nH
L4504 1-469-525-91 INDUCTOR 10uH
< RESISTOR >
R4501 1-216-864-11 SHORT CHIP 0
R4502 1-216-864-11 SHORT CHIP 0
R4503 1-218-675-11 METAL CHIP 200 0.5% 1/10W
R4504 1-216-864-11 SHORT CHIP 0
R4506 1-216-809-11 METAL CHIP 100 5% 1/10W
R4507 1-216-864-11 SHORT CHIP 0
R4508 1-216-797-11 METAL CHIP 10 5% 1/10W
R4509 1-216-864-11 SHORT CHIP 0
R4510 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4511 1-218-675-11 METAL CHIP 200 0.5% 1/10W
R4513 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R4515 1-216-864-11 SHORT CHIP 0
R4516 1-216-864-11 SHORT CHIP 0
R4517 1-218-675-11 METAL CHIP 200 0.5% 1/10W
R4519 1-216-864-11 SHORT CHIP 0
< TERMINAL >
TB001 1-780-902-11 2P PUSH TERMINAL (ANTENNA AM)
< VIBRATOR >
X4501 1-767-317-11 VIBRATOR, CRYSTAL (32.768 kHz)
*************************************************************
A-1820-896-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C4601 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4602 1-822-423-11 CONNECTOR, USB (A) (
)
< DIODE >
D4605 6-500-848-01 DIODE MC2840-T112-1
< JUMPER RESISTOR >
R4601 1-216-864-11 SHORT CHIP 0
R4602 1-216-864-11 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
59 1-500-082-11 CLAMP, SLEEVE FERRITE
61 1-839-673-21 CABLE, FLEXIBLE FLAT (19 CORE)
62 1-839-489-21 CABLE, FLEXIBLE FLAT (7 CORE)
TUNER USB
101 1-481-530-21 FILTER, CLAMP (FERRITE CORE)
104 1-839-670-21 CABLE, FLEXIBLE FLAT (8 CORE) (G2BNiP)
106 1-839-671-21 CABLE, FLEXIBLE FLAT (9 CORE)
107 1-457-413-11 CORE, FERRITE
153 1-839-672-21 CABLE, FLEXIBLE FLAT (15 CORE)
154 1-457-413-11 CORE, FERRITE
155 1-500-082-11 CLAMP, SLEEVE FERRITE
156 1-481-530-21 FILTER, CLAMP (FERRITE CORE)
161 1-839-674-21 CABLE, FLEXIBLE FLAT (21 CORE)
205 1-481-530-21 FILTER, CLAMP (FERRITE CORE)
207 1-832-534-21 CABLE, FLEXIBLE FLAT (5 CORE)
208 1-832-615-21 CABLE, FLEXIBLE FLAT (21 CORE)
251 A-1242-967-B LOADING (BK) ASSY (Including MOTOR board)
0 256 A-4735-357-A BASE ASSY, OP (KSM-213D)
(Including sled motor, spindle motor)
257 1-834-268-21 WIRE (FLAT TYPE) (16 CORE)
0 AC1 1-697-045-11 AC INLET (2P)
ANT1 1-754-804-11 ANTENNA, 2.4 GHZ
CN01 1-820-441-11 CONNECTOR, COAXIAL (F TYPE) (G2BNiP)
DAB1 1-489-807-11 MODULE (DAB TUNER) (G2BNiP)
MOD1 A-1861-411-A MODULE (SERVICE) (WIRELESS LAN MODULE)
0 T901 1-697-042-11 TRANSFORMER, POWER (AUS)
0 T901 1-697-044-11 TRANSFORMER, POWER (AEP, UK)
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
