HCD-GN700/GX8800
2727
T331 5
r
WAVEFORMS
1
IC501 qa XC-OUT
2
3
IC501 qd X-OUT
T331 4
4
– MAIN BOARD –
– CD BOARD –
IC101 el FE
2
IC101 ra TE
1
IC101 t; RFAC
3
– DISPLAY BOARD –
IC601 is X OUT
1
3.0Vp-p
32KHz
VOL/DIV : 1V AC
TIME/DIV : 10 µ sec
VOL/DIV : 1V AC
TIME/DIV : 50nsec
2.0Vp-p
16MHz
240Vp-p
13
µ sec
VOL/DIV : 50V AC
TIME/DIV : 10 µ sec
TAPE REC only
VOL/DIV : 50V AC
TIME/DIV : 10 µ sec
TAPE REC only
64Vp-p
13
µ sec
4MHz
2.4Vp-
p
VOL/DIV : 1V AC
TIME/DIV : 0.2 µ sec
VOL/DIV : 0.1V AC
TIME/DIV : 1msec
VOL/DIV : 0.2V AC
TIME/DIV : 0.2msec
VOL/DIV : 0.2V AC
TIME/DIV : 0.5
µ sec
0.15Vp-p
0.4Vp-
p
0.96Vp-p
