87
HCD-GNZ55D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3779 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3781 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3782 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3783 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3784 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3785 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3786 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3787 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0
R3802 1-216-864-11 SHORT CHIP 0
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W
R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5001 1-216-864-11 SHORT CHIP 0
R5012 1-216-864-11 SHORT CHIP 0
R5016 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB103 1-234-795-21 RES, NETWORK 0X4 (2010)
RB104 1-234-795-21 RES, NETWORK 0X4 (2010)
RB105 1-234-371-21 RES, NETWORK 47X4 (1005)
RB106 1-234-371-21 RES, NETWORK 47X4 (1005)
RB107 1-234-370-21 RES, NETWORK 22X4 (1005)
RB108 1-234-370-21 RES, NETWORK 22X4 (1005)
RB111 1-234-795-21 RES, NETWORK 0X4 (2010)
RB112 1-234-370-21 RES, NETWORK 22X4 (1005)
RB113 1-234-370-21 RES, NETWORK 22X4 (1005)
< VIBRATOR >
X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
*************************************************************
A-1103-756-B DRIVER BOARD, COMPLETE
***********************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-21 CERAMIC 0.1uF 50V
C736 1-164-159-21 CERAMIC 0.1uF 50V
C737 1-164-159-21 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< DIODE >
D701 8-719-921-42 DIODE MTZJ-5.1A
D711 8-719-109-69 DIODE RD3.6ESB2
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R736 1-249-412-11 CARBON 390 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
*************************************************************
IR BOARD
*********
< CAPACITOR >
C1308 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
< CONNECTOR >
CN1403 1-816-423-11 SOCKET, CONNECTOR 3P
< IC >
IC1301 6-600-309-01 IC RPM7240-H9 (IR)
< RESISTOR >
R1306 1-216-805-11 METAL CHIP 47 5% 1/10W
*************************************************************
A-1159-563-A MAIN BOARD, COMPLETE (E3)
A-1189-052-A MAIN BOARD, COMPLETE (PH)
A-1189-055-A MAIN BOARD, COMPLETE (MY,SP)
A-1189-058-A MAIN BOARD, COMPLETE (EA)
A-1189-061-A MAIN BOARD, COMPLETE (E12)
A-1189-064-A MAIN BOARD, COMPLETE (E15)
A-1189-067-A MAIN BOARD, COMPLETE (E13)
A-1189-077-A MAIN BOARD, COMPLETE (TH)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20% 50V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
DMB15 IRDRIVER MAIN
