97
HCD-GNZ55D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R807 1-216-864-11 SHORT CHIP 0
R808 1-216-864-11 SHORT CHIP 0
R810 1-216-864-11 SHORT CHIP 0
R811 1-216-845-11 METAL CHIP 100K 5% 1/10W
R820 1-216-837-11 METAL CHIP 22K 5% 1/10W
R821 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R824 1-216-837-11 METAL CHIP 22K 5% 1/10W
R825 1-216-837-11 METAL CHIP 22K 5% 1/10W
R827 1-216-864-11 SHORT CHIP 0
R840 1-216-845-11 METAL CHIP 100K 5% 1/10W
R841 1-216-864-11 SHORT CHIP 0
R842 1-216-864-11 SHORT CHIP 0
R843 1-216-864-11 SHORT CHIP 0
R844 1-216-864-11 SHORT CHIP 0
R845 1-216-864-11 SHORT CHIP 0
R860 1-216-845-11 METAL CHIP 100K 5% 1/10W
R861 1-216-845-11 METAL CHIP 100K 5% 1/10W
R862 1-216-845-11 METAL CHIP 100K 5% 1/10W
R865 1-216-845-11 METAL CHIP 100K 5% 1/10W
R866 1-216-845-11 METAL CHIP 100K 5% 1/10W
R867 1-216-845-11 METAL CHIP 100K 5% 1/10W
R868 1-216-841-11 METAL CHIP 47K 5% 1/10W
R869 1-216-841-11 METAL CHIP 47K 5% 1/10W
R880 1-216-837-11 METAL CHIP 22K 5% 1/10W
R881 1-216-837-11 METAL CHIP 22K 5% 1/10W
R882 1-216-837-11 METAL CHIP 22K 5% 1/10W
R883 1-216-837-11 METAL CHIP 22K 5% 1/10W
R884 1-216-837-11 METAL CHIP 22K 5% 1/10W
R885 1-216-839-11 METAL CHIP 33K 5% 1/10W
R886 1-216-864-11 SHORT CHIP 0
R887 1-216-837-11 METAL CHIP 22K 5% 1/10W
R888 1-216-837-11 METAL CHIP 22K 5% 1/10W
R889 1-216-837-11 METAL CHIP 22K 5% 1/10W
R890 1-216-837-11 METAL CHIP 22K 5% 1/10W
R891 1-216-839-11 METAL CHIP 33K 5% 1/10W
R892 1-216-864-11 SHORT CHIP 0
R893 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R894 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R895 1-216-837-11 METAL CHIP 22K 5% 1/10W
< VIBRATOR >
X801 1-795-660-21 QUARTZ CRYSTAL UNIT (49MHz)
*************************************************************
A-1164-023-A VIDEO BOARD, COMPLETE
**********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
< CAPACITOR >
C1850 1-126-916-11 ELECT 1000uF 20% 6.3V
C1851 1-126-960-11 ELECT 1uF 20% 50V
C1871 1-216-864-11 SHORT CHIP 0
C1876 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1878 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1881 1-104-658-11 ELECT 100uF 20% 10V
C1882 1-126-960-11 ELECT 1uF 20% 50V
C1883 1-126-926-11 ELECT 1000uF 20% 10V
C1884 1-126-960-11 ELECT 1uF 20% 50V
C1885 1-126-916-11 ELECT 1000uF 20% 6.3V
C1886 1-126-960-11 ELECT 1uF 20% 50V
C1887 1-126-916-11 ELECT 1000uF 20% 6.3V
C1888 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN1880 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN1966 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
< GROUND TERMINAL >
EPT1970 1-537-738-21 TERMINAL, GROUND
< JUMPER RESISTOR >
FB1976 1-216-864-11 SHORT CHIP 0
FB1979 1-216-864-11 SHORT CHIP 0
< IC >
IC1800 6-600-495-01 IC MM1671XNRE
IC1802 8-759-653-07 IC PQ09RD21J00H
IC1803 6-707-921-01 IC PQ3RD13J000H
IC1804 8-759-471-81 IC PQ05RD11J00H
< JACK >
J1900 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JR1914 1-216-864-11 SHORT CHIP 0
< COIL >
L1950 1-414-183-41 INDUCTOR 10uH
< TRANSISTOR >
Q1970 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1971 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1941 1-218-285-11 METAL CHIP 75 5% 1/10W
R1942 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1947 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
VOLUME BOARD
**************
< CAPACITOR >
C1334 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D1309 6-500-809-01 LED SELU5223C-STP15
(RING ILLUMINATION)
D1312 6-500-809-01 LED SELU5223C-STP15
(RING ILLUMINATION)
< JUMPER RESISTOR >
JR1300 1-216-864-11 SHORT CHIP 0
JR1301 1-216-864-11 SHORT CHIP 0
S-MASTER VIDEO VOLUME
