Sony HCD-GPX7 - Lever (Loading-L;R)

HCD-GPX6/GPX7
14
lever (loading-R)
Align the horizontal position.
lever (loading-L)
Install the both levers so that they move symmetrically.
– Bottom view –
2 two hooks
4 two hooks
3 lever (loading-L)
5 lever (loading-R)
SPT-T (loading-R) SPT-T (loading-L)
1
1
PRECAUTION DURING LEVER (LOADING R / L) INSTALLATION
3-12. LEVER (LOADING-L/R)
