Sony HCD-GPX7 - Printed Wiring Board - DRIVER Board

HCD-GPX6/GPX7
2828
6-7. PRINTED WIRING BOARD – DRIVER Board – • See page 25 for Circuit Boards Location. :Uses unleaded solder.
C711
IC701
S701S703
R702
R701
D701
C705
CN701
S702
DRIVER BOARD
1-688-337-
12
(12)
M701
(LOADING)
M
MAIN BOARD
CN303
B
(CHUCK)
(OUT)(TRIGGER)
19
(Page 30)
