Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
HCD-GPX6/GPX7
< CONNECTOR >
CN701 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-951-13 SWITCH, PUSH (OUT)
S702 1-762-951-13 SWITCH, PUSH (CHUCK)
S703 1-762-951-13 SWITCH, PUSH (TRIGGER)
************************************************************
A-1052-489-A MAIN BOARD, COMPLETE (US)
A-1059-491-A MAIN BOARD, COMPLETE (HK, SP)
A-1059-528-A MAIN BOARD, COMPLETE (KR)
A-1059-562-A MAIN BOARD, COMPLETE (AUS)
A-1061-983-A MAIN BOARD, COMPLETE (AR)
A-4751-274-A MAIN BOARD, COMPLETE (AEP)
*********************
< CAPACITOR >
C101 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C105 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C106 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C107 1-130-479-00 MYLAR 0.0047uF 5% 50V
C109 1-126-964-11 ELECT 10uF 20% 50V
C110 1-126-964-11 ELECT 10uF 20% 50V
C111 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C112 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C113 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C114 1-126-960-11 ELECT 1uF 20% 50V
C115 1-126-964-11 ELECT 10uF 20% 50V
C116 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-126-964-11 ELECT 10uF 20% 50V
C118 1-126-964-11 ELECT 10uF 20% 50V
C119 1-126-964-11 ELECT 10uF 20% 50V
C122 1-130-475-00 MYLAR 0.0022uF 5% 50V
(GPX6)
C122 1-130-476-00 MYLAR 0.0027uF 5% 50V
(GPX7)
C123 1-130-495-00 MYLAR 0.1uF 5% 50V
(GPX6)
C123 1-130-499-00 MYLAR 0.22uF 5% 50V
(GPX7)
C124 1-126-967-11 ELECT 47uF 20% 50V
C125 1-126-965-11 ELECT 22uF 20% 50V
C128 1-126-964-11 ELECT 10uF 20% 50V
C131 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C133 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP, KR)
C134 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP, KR)
C135 1-162-306-11 CERAMIC 0.01uF 20% 16V
C137 1-126-965-11 ELECT 22uF 20% 50V
C138 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C141 1-126-964-11 ELECT 10uF 20% 50V
C201 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C205 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C206 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C207 1-130-479-00 MYLAR 0.0047uF 5% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C212 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C213 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C214 1-126-960-11 ELECT 1uF 20% 50V
C215 1-126-964-11 ELECT 10uF 20% 50V
C216 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C217 1-126-964-11 ELECT 10uF 20% 50V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C222 1-130-475-00 MYLAR 0.0022uF 5% 50V
(GPX6)
C222 1-130-476-00 MYLAR 0.0027uF 5% 50V
(GPX7)
C223 1-130-495-00 MYLAR 0.1uF 5% 50V
(GPX6)
C223 1-130-499-00 MYLAR 0.22uF 5% 50V
(GPX7)
C224 1-126-967-11 ELECT 47uF 20% 50V
C225 1-126-965-11 ELECT 22uF 20% 50V
C228 1-126-964-11 ELECT 10uF 20% 50V
C231 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C233 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP, KR)
C234 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP, KR)
C235 1-162-306-11 CERAMIC 0.01uF 20% 16V
C237 1-126-965-11 ELECT 22uF 20% 50V
C238 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C241 1-126-964-11 ELECT 10uF 20% 50V
C302 1-137-150-11 FILM 0.01uF 5% 100V
C303 1-124-257-00 ELECT 2.2uF 20% 50V
C304 1-126-964-11 ELECT 10uF 20% 50V
C305 1-126-947-11 ELECT 47uF 20% 35V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-130-485-00 MYLAR 0.015uF 5% 50V
C308 1-130-481-00 MYLAR 0.0068uF 5% 50V
C309 1-130-481-00 MYLAR 0.0068uF 5% 50V
C310 1-130-486-00 MYLAR 0.018uF 5% 50V
C314 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C317 1-126-965-11 ELECT 22uF 20% 50V
C318 1-126-935-11 ELECT 470uF 20% 16V
C319 1-126-935-11 ELECT 470uF 20% 16V
C320 1-126-934-11 ELECT 220uF 20% 16V
DRIVER MAIN
