Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
69
HCD-GPX6/GPX7
< RESISTOR >
R901 1-249-417-11 CARBON 1K 5% 1/4W
R902 1-249-417-11 CARBON 1K 5% 1/4W
0 R903 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
0 R904 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
0 R905 1-202-973-61 FUSIBLE 3.3 5% 1/4W F
0 R906 1-219-237-51 SOLID 3.3M 20% 1/2W
(US)
R909 1-249-421-11 CARBON 2.2K 5% 1/4W
< RELAY >
0 RY901 1-755-324-11 RELAY
< SWITCH >
0 S901 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(HK, SP)
************************************************************
MISCELLANEOUS
**************
108 1-796-351-41 MECHANISM, SIGNAL CASSETTE
(CMAL1Z234A)
204 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
0 206 1-769-079-23 CORD, POWER (KR)
0 206 1-769-744-52 CORD, POWER (HK, SP, AEP)
0 206 1-775-790-12 CORD, POWER (AUS)
0 206 1-783-531-22 CORD, POWER (US)
0 206 1-829-387-11 CORD, POWER (AR)
208 1-468-738-11 REGULATOR, SWITCHING
209 1-693-625-11 TUNER (FM/AM) (US)
209 1-693-626-11 TUNER (FM/AM) (AEP)
209 1-693-628-11 TUNER (FM/AM) (HK, SP, AUS, AR)
209 1-693-629-11 TUNER (FM/AM) (KR)
462 1-452-925-21 MAGNET ASSY
0 657 8-820-244-11 OPTICAL PICK-UP KSM-215DCP/C2NP
658 1-827-992-11 WIRE (FLAT TYPE) (16 CORE)
0 F901 1-533-451-12 FUSE, GLASS TUBE (DIA. 5) (3.15A/125V)
(US)
0 F901 1-533-470-12 FUSE, GLASS TUBE (DIA. 5) (T3.15A/250V)
(HK, SP, KR, AUS)
0 F901 1-533-471-12 FUSE, GLASS TUBE (DIA. 5) (T4A/250V)
(AEP, AR)
0 F902 1-533-451-12 FUSE, GLASS TUBE (DIA. 5) (3.15A/125V)
(US)
0 F902 1-533-470-12 FUSE, GLASS TUBE (DIA. 5) (T3.15A/250V)
(HK, SP, KR, AUS)
0 F902 1-533-471-12 FUSE, GLASS TUBE (DIA. 5) (T4A/250V)
(AEP, AR)
0 F903 1-533-467-12 FUSE, GLASS TUBE (DIA. 5) (T1.6A/250V)
(HK, SP)
M301 1-787-103-11 FAN, DC (US, AEP, AR)
M701 X-2021-530-1 MOTOR (PULLEY) ASSY (LOADING)
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
0 T901 1-443-197-11 TRANSFORMER, POWER (AEP, AR)
0 T901 1-443-204-11 TRANSFORMER, POWER (US)
0 T901 1-443-205-11 TRANSFORMER, POWER (HK, SP, KR, AUS)
**********************************************************************
POWER
ACCESSORIES
************
1-569-008-32 ADAPTOR, CONVERSION (SP)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
