ā 81 ā
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JOG
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-223-587-11 RES, ADJ, CARBON 22K
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-223-587-11 RES, ADJ, CARBON 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV103 1-223-587-11 RES, ADJ, CARBON 22K
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-659-331-11 HP BOARD
********
< CAPACITOR >
C520 1-162-306-11 CERAMIC 0.01uF 20% 16V
C521 1-162-306-11 CERAMIC 0.01uF 20% 16V
C640 1-162-306-11 CERAMIC 0.01uF 20% 16V
C641 1-124-257-00 ELECT 2.2uF 20% 50V
C642 1-162-294-31 CERAMIC 0.001uF 10% 50V
C643 1-162-282-31 CERAMIC 100PF 10% 50V
C644 1-162-290-31 CERAMIC 470PF 10% 50V
C645 1-124-465-00 ELECT 0.47uF 20% 50V
C646 1-162-282-31 CERAMIC 100PF 10% 50V
HPBD
C647 1-162-282-31 CERAMIC 100PF 10% 50V
C648 1-124-257-00 ELECT 2.2uF 20% 50V
C649 1-124-589-11 ELECT 47uF 20% 16V
C650 1-124-589-11 ELECT 47uF 20% 16V
C651 1-162-306-11 CERAMIC 0.01uF 20% 16V
C9998 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
* CN513 1-568-935-11 PIN, CONNECTOR 8P
< IC >
IC601 8-759-634-51 IC M5218AP
< JACK >
J501 1-778-605-11 JACK (LARGE TYPE)(PHONES)
(EXCEPT AEP,UK,G,EE,IA)
J501 1-774-728-11 JACK (PHONES) (IA)
J501 1-770-226-11 JACK (LARGE TYPE)(PHONES)(AEP,UK,G,EE)
J601 1-778-605-11 JACK (LARGE TYPE)(MIX MIC)
(EXCEPT AEP,UK,G,EE,IA)
J601 1-774-728-11 JACK (MIX MIC) (IA)
J601 1-770-226-11 JACK (LARGE TYPE)(MIX MIC)(AEP,UK,G,EE)
< RESISTOR >
R640 1-249-429-11 CARBON 10K 5% 1/4W
R641 1-249-441-11 CARBON 100K 5% 1/4W
R642 1-249-417-11 CARBON 1K 5% 1/4W
R643 1-249-417-11 CARBON 1K 5% 1/4W
R644 1-249-435-11 CARBON 33K 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
R646 1-247-881-00 CARBON 120K 5% 1/4W
R647 1-247-807-31 CARBON 100 5% 1/4W
************************************************************
* 1-659-333-11 JOG BOARD
*********
< CAPACITOR >
C524 1-162-306-11 CERAMIC 0.01uF 20% 16V
C525 1-162-306-11 CERAMIC 0.01uF 20% 16V
C526 1-162-306-11 CERAMIC 0.01uF 20% 16V
C527 1-162-306-11 CERAMIC 0.01uF 20% 16V
< DIODE >
D582 8-719-812-44 DIODE TLO124 (ENTER/NEXT)
< RESISTOR >
R511 1-249-409-11 CARBON 220 5% 1/4W
R512 1-249-411-11 CARBON 330 5% 1/4W
R513 1-249-413-11 CARBON 470 5% 1/4W
R514 1-249-415-11 CARBON 680 5% 1/4W
R560 1-249-417-11 CARBON 1K 5% 1/4W
R582 1-249-407-11 CARBON 150 5% 1/4W
< SWITCH >
S511 1-554-303-21 SWITCH, TACTILE (FREQUENCY -)
S512 1-554-303-21 SWITCH, TACTILE (FREQUENCY +)
S513 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S514 1-554-303-21 SWITCH, TACTILE (DBFB)
