— 82 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S560 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S561 1-467-869-11 ENCODER, ROTARY (VOLUME)
S562 1-467-968-11 ENCODER, ROTARY (MULTI JOG STATION)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR
PHOTO REFLECTOR NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR
PHOTO REFLECTOR NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-571-281-21 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* 1-650-836-11 LOADING BOARD
*************
< CONNECTOR >
* CN291 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S291 1-572-086-11 SWITCH, LEAF (LOAD OUT)
S292 1-572-086-11 SWITCH, LEAF (LOAD IN)
************************************************************
* A-4386-430-A MAIN BOARD, COMPLETE (AEP,UK)
* A-4386-432-A MAIN BOARD, COMPLETE (JE)
* A-4386-433-A MAIN BOARD, COMPLETE (G)
* A-4386-434-A MAIN BOARD, COMPLETE
(E,EA3,MY,SP,HK,TW)
* A-4386-436-A MAIN BOARD, COMPLETE (EE)
* A-4386-437-A MAIN BOARD, COMPLETE (IA)
* A-4386-439-A MAIN BOARD, COMPLETE (EA4,TH)
*******************************
* 1-537-738-21 TERMINAL, EARTH (EA4,TH)
1-537-770-21 TERMINAL BOARD, GROUND (AEP,UK,G,EE)
1-533-217-31 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C201 1-126-961-11 ELECT 2.2uF 20% 50V
C202 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C203 1-124-472-11 ELECT 470uF 20% 10V
C204 1-162-282-31 CERAMIC 100PF 10% 50V
C205 1-162-282-31 CERAMIC 100PF 10% 50V
C206 1-162-306-11 CERAMIC 0.01uF 20% 16V
C207 1-162-306-11 CERAMIC 0.01uF 20% 16V
C208 1-162-306-11 CERAMIC 0.01uF 20% 16V
C209 1-126-952-11 ELECT 1000uF 20% 16V
(EXCEPT EA4,TH)
C209 1-126-797-11 ELECT 1000uF 20% 10V
(EA4,TH)
C210 1-162-306-11 CERAMIC 0.01uF 20% 16V
C211 1-126-933-11 ELECT 100uF 20% 10V
C251 1-126-961-11 ELECT 2.2uF 20% 50V
C252 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C301 1-130-479-00 MYLAR 0.0047uF 5% 50V
C302 1-162-290-31 CERAMIC 470PF 10% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-964-11 ELECT 10uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-126-960-11 ELECT 1uF 20% 50V
C310 1-126-933-11 ELECT 100uF 20% 10V
C351 1-130-479-00 MYLAR 0.0047uF 5% 50V
C352 1-162-290-31 CERAMIC 470PF 10% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-960-11 ELECT 1uF 20% 50V
C357 1-126-964-11 ELECT 10uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-126-960-11 ELECT 1uF 20% 50V
C360 1-126-933-11 ELECT 100uF 20% 10V
C401 1-164-159-11 CERAMIC 0.1uF 50V
C402 1-164-159-11 CERAMIC 0.1uF 50V
C403 1-164-159-11 CERAMIC 0.1uF 50V
C404 1-126-933-11 ELECT 100uF 20% 16V
C405 1-126-935-11 ELECT 470uF 20% 16V
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-926-11 ELECT 1000uF 20% 10V
C703 1-126-964-11 ELECT 10uF 20% 50V
C704 1-136-165-00 MYLAR 0.1uF 10% 50V
C705 1-136-165-00 FILM 0.1uF 5% 50V
C706 1-126-965-11 ELECT 22uF 20% 50V
C707 1-162-205-31 CERAMIC 18PF 5% 50V
C708 1-162-205-31 CERAMIC 18PF 5% 50V
C710 1-162-306-11 CERAMIC 0.01uF 20% 16V
C713 1-162-306-11 CERAMIC 0.01uF 20% 16V
C720 1-164-159-11 CERAMIC 0.1uF 50V
C789 1-126-923-11 ELECT 220uF 20% 10V
C810 1-162-306-11 CERAMIC 0.01uF 20% 16V
C811 1-162-306-11 CERAMIC 0.01uF 20% 16V
C821 1-162-286-31 CERAMIC 220PF 10% 50V
C825 1-109-889-11 ELECT 1uF 20% 50V
C831 1-162-286-31 CERAMIC 220PF 10% 50V
C871 1-162-286-31 CERAMIC 220PF 10% 50V
C881 1-162-286-31 CERAMIC 220PF 10% 50V
C901 1-136-169-00 FILM 0.22uF 5% 50V
C902 1-136-169-00 FILM 0.22uF 5% 50V
LEAF SWITCH
MAIN
LOADING
JOG
