Sony HCD-GTR33 - Top Case; Tape Mechanism Deck

HCD-GTR33/GTR55/GTR77
6
2-4. TAPE MECHANISM DECK (For African model only)
6 bracket (deck)
5 two screws
(BVTP2.6 u8)
7 two screws
(BVTP2.6 u8)
9 tape mechanism deck
1 CN501 (8P)
3 two screws
(BVTP3 u 8)
2 Cut the clamp.
8 Open the cassette box.
4 TC board
top panel block
2-3. TOP CASE
1 one screw
(BVTP3 u 8)
3 two claws
2 wire (flat type) (9 core)
(CN450)
4 Lift up the back
side of top case.
5 top case
Tape deck section
(For African Model only)
