Sony HCD-GTR33 - MAIN Board Parts List (Part 3)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
6565
JR422 1-216-296-11 SHORT CHIP 0
JR423 1-216-864-11 SHORT CHIP 0
JR424 1-216-296-11 SHORT CHIP 0
JR425 1-216-296-11 SHORT CHIP 0
JR426 1-216-296-11 SHORT CHIP 0
JR427 1-216-864-11 SHORT CHIP 0
JR428 1-216-296-11 SHORT CHIP 0
JR429 1-216-864-11 SHORT CHIP 0
JR430 1-216-296-11 SHORT CHIP 0
JR431 1-216-864-11 SHORT CHIP 0
JR432 1-216-296-11 SHORT CHIP 0
JR433 1-216-296-11 SHORT CHIP 0
JR434 1-216-296-11 SHORT CHIP 0
JR435 1-216-296-11 SHORT CHIP 0
JR436 1-216-296-11 SHORT CHIP 0
JR437 1-216-864-11 SHORT CHIP 0
JR438 1-216-864-11 SHORT CHIP 0
JR439 1-216-296-11 SHORT CHIP 0
JR440 1-216-296-11 SHORT CHIP 0
JR447 1-216-296-11 SHORT CHIP 0
JR449 1-216-296-11 SHORT CHIP 0
JR500 1-216-864-11 SHORT CHIP 0 (E4)
JR503 1-216-864-11 SHORT CHIP 0
JR634 1-216-296-11 SHORT CHIP 0
JR635 1-216-296-11 SHORT CHIP 0
JR636 1-216-296-11 SHORT CHIP 0
JR637 1-216-864-11 SHORT CHIP 0
JR638 1-216-296-11 SHORT CHIP 0
JR639 1-216-296-11 SHORT CHIP 0
JR640 1-216-864-11 SHORT CHIP 0
< COIL >
L623 1-400-424-21 INDUCTOR 47uH
L624 1-457-822-11 INDUCTOR 47uH
< TRANSISTOR >
Q115 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q128 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q178 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q210 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q211 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q212 8-729-037-13 TRANSISTOR KTA1271Y
Q214 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q215 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q230 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR55/GTR77)
Q231 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR55/GTR77)
Q300 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q301 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q303 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q402 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q430 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q431 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q452 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q500 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q501 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q502 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q503 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q620 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q627 8-729-027-26 TRANSISTOR DTA114YKA-T146
Q628 6-551-276-01 TRANSISTOR RT1N431C-TP-1
Q640 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q641 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q643 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q644 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q645 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q646 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q647 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q648 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q655 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q656 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q657 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q658 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q670 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q681 6-551-276-01 TRANSISTOR RT1N431C-TP-1 (E4)
Q682 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF (E4)
Q683 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF (E4)
Q684 8-729-037-13 TRANSISTOR KTA1271Y (E4)
Q696 8-729-032-94 TRANSISTOR 2SD1859TV2Q
Q697 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q698 8-729-032-94 TRANSISTOR 2SD1859TV2Q
(GTR55/GTR77)
Q699 8-729-037-13 TRANSISTOR KTA1271Y
< RESISTOR >
R110 1-216-845-11 METAL CHIP 100K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R112 1-216-817-11 METAL CHIP 470 5% 1/10W
R113 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-837-11 METAL CHIP 22K 5% 1/10W
R118 1-216-838-11 METAL CHIP 27K 5% 1/10W
R120 1-216-838-11 METAL CHIP 27K 5% 1/10W
R121 1-216-833-11 METAL CHIP 10K 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R127 1-216-819-11 METAL CHIP 680 5% 1/10W
(GTR55)
R127 1-220-373-11 METAL CHIP 620 5% 1/10W
(GTR33/GTR77)
R128 1-216-834-11 METAL CHIP 12K 5% 1/10W
(GTR33)
R128 1-216-835-11 METAL CHIP 15K 5% 1/10W
(GTR55/GTR77)
R129 1-216-864-11 SHORT CHIP 0
R130 1-216-849-11 METAL CHIP 220K 5% 1/10W
R131 1-216-849-11 METAL CHIP 220K 5% 1/10W
R132 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R133 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R137 1-216-833-11 METAL CHIP 10K 5% 1/10W
R138 1-216-841-11 METAL CHIP 47K 5% 1/10W
R144 1-216-820-11 METAL CHIP 820 5% 1/10W
R145 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R153 1-216-833-11 METAL CHIP 10K 5% 1/10W
R177 1-216-819-11 METAL CHIP 680 5% 1/10W
(GTR55)
MAIN
