Sony HCD-GTR33 - TC, TRANS, and USB Board Parts List (Continued)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
7171
R506 1-216-834-11 METAL CHIP 12K 5% 1/10W
R507 1-216-850-11 METAL CHIP 270K 5% 1/10W
R508 1-216-850-11 METAL CHIP 270K 5% 1/10W
R509 1-216-814-11 METAL CHIP 270 5% 1/10W
R510 1-216-814-11 METAL CHIP 270 5% 1/10W
R511 1-216-845-11 METAL CHIP 100K 5% 1/10W
R512 1-216-845-11 METAL CHIP 100K 5% 1/10W
R513 1-216-845-11 METAL CHIP 100K 5% 1/10W
R514 1-216-845-11 METAL CHIP 100K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-864-11 SHORT CHIP 0
R517 1-216-821-11 METAL CHIP 1K 5% 1/10W
R518 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-841-11 METAL CHIP 47K 5% 1/10W
R520 1-216-841-11 METAL CHIP 47K 5% 1/10W
R521 1-216-841-11 METAL CHIP 47K 5% 1/10W
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
R523 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R524 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R525 1-216-851-11 METAL CHIP 330K 5% 1/10W
R526 1-216-851-11 METAL CHIP 330K 5% 1/10W
R527 1-216-851-11 METAL CHIP 330K 5% 1/10W
R528 1-216-851-11 METAL CHIP 330K 5% 1/10W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R530 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R531 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R532 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R533 1-216-837-11 METAL CHIP 22K 5% 1/10W
R534 1-216-835-11 METAL CHIP 15K 5% 1/10W
R535 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R536 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R537 1-216-833-11 METAL CHIP 10K 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R539 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R540 1-216-805-11 METAL CHIP 47 5% 1/10W
R541 1-216-805-11 METAL CHIP 47 5% 1/10W
R543 1-216-813-11 METAL CHIP 220 5% 1/10W
R544 1-216-813-11 METAL CHIP 220 5% 1/10W
R545 1-216-817-11 METAL CHIP 470 5% 1/10W
R546 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S501 1-762-369-11 SWITCH, SLIDE (REC/PB)
*************************************************************
TRANS BOARD
************
< CAPACITOR >
C903 1-136-153-00 FILM 0.01uF 5% 50V
C904 1-136-153-00 FILM 0.01uF 5% 50V
C908 1-128-576-11 ELECT 100uF 20% 63V
C909 1-126-964-11 ELECT 10uF 20% 50V
C910 1-126-968-11 ELECT 100uF 20% 50V
C911 1-126-767-11 ELECT 1000uF 20% 16V
C927 1-126-962-11 ELECT 3.3uF 20% 50V
< CONNECTOR >
CN901 1-691-961-11 PIN, CONNECTOR (PC BOARD) 3P
* CN907 1-764-334-11 PLUG, CONNECTOR 11P 11P
* CN908 1-564-509-11 PLUG, CONNECTOR 6P
(GTR55/GTR77)
* CN909 1-564-507-11 PLUG, CONNECTOR 4P (GTR33)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-991-33 DIODE 1SS133T-77
D903 8-719-991-33 DIODE 1SS133T-77
D904 8-719-991-33 DIODE 1SS133T-77
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 6-500-522-21 DIODE 10EDB40-TB3
D909 8-719-983-92 DIODE MTZJ-T-72-36B
< FUSE >
0 F951 1-523-080-11 FUSE 6.3A 250V
0 F952 1-523-080-11 FUSE 6.3A 250V (GTR55/GTR77)
0 F953 1-523-080-11 FUSE 6.3A 250V (GTR55/GTR77)
0 F954 1-523-080-11 FUSE 6.3A 250V
0 F955 1-523-082-11 FUSE 1A 250V (GTR77: MX)
0 F956 1-523-086-11 FUSE 3.15A 250V
< TRANSFORMER >
0 PT902 1-443-927-21 TRANSFORMER, POWER (SUB) (MX)
0 PT902 1-445-875-11 POWER TRANSFORMER (SUB) (EXCEPT MX)
< TRANSISTOR >
Q902 8-729-048-66 TRANSISTOR 2SB1238-PQR-TV2
Q903 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R904 1-247-831-91 CARBON 1K 5% 1/4W
R915 1-247-847-91 CARBON 4.7K 5% 1/4W
R952 1-249-429-11 CARBON 10K 5% 1/4W
0 R955 1-217-637-55 FUSIBLE 1 5% 1/4W
(EXCEPT GTR77: MX)
R957 1-249-424-11 CARBON 3.9K 5% 1/4W
< RELAY >
0 RY901 1-755-334-11 RELAY, AC POWER
< SWITCH >
0 S901 1-786-055-31 SELECTOR, VOLTAGE (E2, E51, E4)
*************************************************************
USB BOARD
**********
< CAPACITOR >
C1002 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1003 1-126-176-11 ELECT 220uF 20% 10V
C1004 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1005 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1006 1-126-176-11 ELECT 220uF 20% 10V
C1007 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1008 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1009 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1010 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1011 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
TC TRANS USB
